Name: LG UH5J 86 4K Smart LED Commercial Display
Brand: LG
SKU: 86UH5J-H
Price: 7589 AUD
Availability: InStock

LG UH5J 86" 4K Smart LED Commercial Display

SKU : 86UH5J-H

Brand : LG

Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse

Estimated Shipping

Find

Description
Specifications
Reviews

Product Description

Manufacture # LG | Model # 86UH5J-H

With a recommend brightness of 500 cd/m² for indoor display, the UH5J-H series clearly delivers content and attracts public attention, making it the most suitable display for marketing in meeting rooms, airports, retail, shopping malls, etc.

Features:

In various places the UH5J-H series is unable to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on power board reduces these risks by protecting UH5J-H series from salt, dust, iron powder, humidity, etc.
The UH5J-H series has supported Crestron Connected for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.
The IP5x Dust-Proof Certification ensures that the product is protected from dust, reducing the risk of performance degradation.

Overview:

Screen Size: 86" IPS
Back Light Type: Edge
Aspect Ratio: 16:9
Native Resolution: 3840 x 2160 (UHD)
Refresh Rate: 120Hz
Brightness: 500nit (Typ.)

Manufacturer Warranty: 03 Years Limited Warranty

Technical Specifications

PANEL
Screen Size (Inch)	86
Panel Technology	IPS
Back Light Type	Edge
Aspect Ratio	16:9
Native Resolution	3840 x 2160 (UHD)
Refresh Rate	120Hz
Brightness	500 nit (Typ.)
Contrast Ratio	1,100:1
Dynamic CR	1,000,000:1
Color Gamut	BT709 95%
Viewing Angle (H x V)	178º x 178º
Color Depth	1.07 Billion colors
Response Time	8ms (G to G)
Surface Treatment	Haze 28%
Lifetime	50,000 Hours (Typ.)
Operation Hours	24/7
Portrait / Landscape	Yes / Yes
Transparency	N/A
QWP (Quarter Wave Plate)	N/A
CONNECTIVITY
HDMI In	Yes (3ea)
HDMI In (HDCP Ver.)	2.2 / 1.4
DP In	Yes (HDCP 2.2 / 1.3)
DVI-D In	Yes (HDCP 1.4)
RGB In	No
Audio In	Yes
RS232C In	Yes
RJ45 (LAN) In	Yes (1ea)
IR In	Yes
USB In	USB 2.0 Type A (1ea)
HDMI Out	Yes
DP Out	No
Audio Out	Yes
Touch USB	No
External Speaker Out	No
RS232C Out	Yes
RJ45 (LAN) Out	No
IR Out	No
Daisy Chain	Input: HDMI, DP / Output: HDMI
MECHANICAL
Bezel Color	Black
Bezel Width	Even bezel: 14.3mm
Weight (Head)	49.0 kg
Weight (Head + Stand)	N/A
Packed Weight	72.5 kg (With Pallet)
Monitor Dimensions (W x H x D)	1926.2 x 1097.2 x 60.6 mm (without Handle and LG Logo)
Monitor Dimension with Stand (W x H x D)	N/A
Carton Dimensions (W x H x D)	2073 x 1250 x 285 mm
Handle	Yes
VESA Standard Mount Interface	600 x 400 mm
FEATURE - HARDWARE
Internal Memory	16 GB
Wi-Fi / BT	Yes
Temperature Sensor	Yes
Auto Brightness Sensor	Yes
Pixel Sensor	No
Proximity Sensor	No
Current Sensor	No
BLU Sensor	No
Humidity Sensor	No
Acceleration (Gyro) Sensor	Yes
Power Indicator	No
Local Key Operation	Yes
FAN (Built-in)	No
FEATURE - SOFTWARE
OS Version	webOS 6.0
Local Contents Scheduling	Yes
Group Manager	Yes
USB Plug & Play	Yes
Fail Over	Yes
Booting Logo Image	Yes
No Signal Image	Yes
RS232C Sync	Yes
Local Network Sync	Yes
Backlight Sync	No
PIP	Yes
PBP	Yes (4PBP)
Screen Share	Yes
Video Tag	Yes (4 Video Tag)
Play via URL	Yes
Screen Rotation	Yes
External Input Rotation	Yes
Gapless Playback	Yes
Tile Mode Setting	Yes
Setting Data Cloning	Yes
SNMP	Yes
ISM Method	Yes
Auto Set ID	Yes
Status Mailing	Yes
Control Manager	Yes
Cisco Certification	Yes
Crestron Connected	Yes
Smart Energy Saving	Yes
PM Mode	Yes
Wake on LAN	Yes
Network Ready	Yes
Beacon	Yes
HDMI-CEC	Yes
SI Server Setting	Yes
webRTC	Yes
Pro	Yes
Brightness Compensation	No
W/B Setting by Grey scale	No
Scan Inversion	No
ENVIRONMENT CONDITIONS
Operation Temperature	0 °C to 40 °C
Operation Humidity	10 % to 80 %
POWER
Power Supply	AC 100-240V~, 50/60Hz
Power Type	Built-in Power
POWER CONSUMPTION
Typical	200W
Maximum	260W
BTU	683 BTU/Hr (Typ.), 888 BTU/Hr (Max.)
Smart Energy Saving	140W (70%)
DPM	0.5W
Power Off	0.5W
SOUND
Speaker (Built-in)	Yes (10W x 2)
CERTIFICATION
Safety	CB / NRTL
EMC	FCC Class "A" / CE / KC
ERP / Energy Star	Yes (NewErP) / Yes
ePEAT (US only)	No
OPS COMPATIBILITY
OPS Type compatible	Yes (Piggyback)
OPS Power Built-in	No
SOFTWARE COMPATIBILITY
SuperSign CMS	Yes
SuperSign Control+	Yes
SuperSign WB	Yes
SuperSign Cloud	Yes
Promota	Yes (Not available for EU/CIS)
Mobile CMS	Yes
Connected Care	Yes
LANGUAGE
OSD	English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Türkçe, Arabic
ACCESSORY
Basic	Remote Controller (including 2 batteries), Power Cord, QSG, Regulation Book, Phone to RS232C Gender
Optional	OPS Kit (KT-OPSF), LSW640A/B (Wall Mount)
SPECIAL FEATURE
Overlay Touch Compatibility	N/A
Smart Calibration	N/A
Tilt (Face up)	N/A
Tilt (Face down)	N/A
IP Rating	N/A
Conformal Coating (Power Board)	Yes
Power Protection	N/A
Direct Sunlight	N/A
