LG UH5J 98" UHD 500 Nits Digital Signage Commercial Display

SKU : 98UH5J-H
Brand : LG
Availablity : Online Only, In Stock
Ships within 1 and 3 days from our Seven Hills, NSW warehouse or Pickup in 3 to 4 days
Screen Size: 98" IPS, Aspect Ratio: 16:9, Native Resolution: 3840 x 2160 (UHD), Refresh Rate: 60Hz, Brightness: 500nit (Typ.), Contrast Ratio: 1,200:1, Back Light Type: Edge, 03 Years Limited Warranty, 98UH5J-H.
Ask a question about this product
Call Us

Estimated Shipping

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # LG | Model # 98UH5J-H



With a great brightness of 700 nits, the UH5J-H series delivers content that can attract attention of viewers and is a suitable display solution for outdoor visibility such as airports, retail, shopping malls etc.


Features:

  • Conformal Coating improves reliability of the circuit board, power board by protecting it against dust, iron powder, humidity etc.
  • You can create a store profile and get template recommendations using the Promota* app. Users can customise templates as needed and easily create and manage content not only on PCs but also on mobile devices.
  • The UH5J-H series has Crestron Connected Certification, a function and network-based control system that is dedicated to meeting rooms and that meets a growing need in the corporate meeting space market.


Overview:

  • Screen Size: 98" IPS
  • Aspect Ratio: 16:9
  • Native Resolution: 3840 x 2160 (UHD)
  • Refresh Rate: 60Hz
  • Brightness: 500nit (Typ.)
  • Contrast Ratio: 1,200:1
  • Back Light Type: Edge



Manufacturer Warranty: 03 Years Limited Warranty

Technical Specifications

PANEL
Screen Size (Inch) 98
Panel Technology IPS
Back Light Type Direct
Aspect Ratio 16:9
Native Resolution 3840 x 2160 (UHD)
Refresh Rate 60Hz
Brightness 500nit (Typ.)
Contrast Ratio 1,200:1
Dynamic CR 1,000,000:1
Color Gamut BT709 95%
Viewing Angle (H x V) 178º x 178º
Color Depth (Number of Colors) 1.07 Billion colors
Response Time 8ms (G to G)
Surface Treatment (Haze) Haze 28%
Life time 50,000Hrs (Typ.)
Operation Hours (Hours/Day) 24/7
Portrait / Landscape YES / YES
Transparency N/A
QWP (Quarter Wave Plate) N/A
CONNECTIVITY
HDMI In YES (3ea)
HDMI In (HDCP Ver.) 2.2/1.4
DP In YES (HDCP 2.2/1.3)
DVI-D In YES (HDCP 1.4)
RGB In NO
Audio In YES
RS232C In YES
RJ45(LAN) In YES (1ea)
IR In YES
USB In USB2.0 Type A (1ea)
HDMI Out YES
DP Out NO
Audio Out YES
Touch USB NO
External Speaker Out NO
RS232C Out YES
RJ45(LAN) Out NO
IR Out NO
Daisy Chain Input: HDMI, DP / Output: HDMI
MECHANICAL SPECIFICATION
Bezel Color Black
Bezel Width Even bezel: 14.9mm
Weight (Head) 66Kg
Weight (Head+Stand) N/A
Packed Weight 99Kg
Monitor Dimensions (W x H x D) 2191.8 x 1246.8 x 86.1mm (without Handle and LG Logo)
Monitor Dimension with Stand N/A
Carton Dimensions (W x H x D) 2342 x 1386 x 420mm
Handle YES
VESA Standard Mount Interface 800 x 400 mm
FEATURE - HARDWARE
Internal Memory (eMMC) 16GB
Wi-Fi/BT (Built-in) YES
Temperature Sensor YES
Auto Brightness Sensor YES
Pixel Sensor NO
Proximity Sensor NO
Current Sensor NO
BLU Sensor NO
Humidity Sensor NO
Acceleration (Gyro) Sensor YES
Power Indicator NO
Local Key Operation YES
FAN (Built-in) NO
FEATURE - SOFTWARE
OS Ver. (webOS) webOS 6.0
Local Contents Scheduling YES
Group Manager YES
USB Plug & Play YES
Fail over YES
Booting Logo Image YES
No Signal Image YES
RS232C Sync YES
Local Network Sync YES
Backlight Sync NO
PIP YES
PBP YES (4PBP)
Screen Share YES
Video Tag YES (4 Video Tag)
Play via URL YES
Screen Rotation YES
External Input Rotation YES
Gapless Playback YES
Tile Mode Setting YES
Setting Data Cloning YES
SNMP YES
ISM Method YES
Auto Set ID YES
Status Mailing YES
Control Manager YES
Cisco Certification YES
Crestron Connected YES
Smart Energy Saving YES
PM mode YES
Wake on LAN YES
Network Ready YES
Beacon YES
HDMI-CEC YES
SI Server Setting YES
webRTC YES
Pro

YES
Brightness Compensation NO
W/B Setting by Grey scale NO
Scan Inversion NO
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C to 40 °C
Operation Humidity 10 % to 80 %
POWER
Power Supply AC 100-240V~, 50/60Hz
Power Type Built-in Power
POWER CONSUMPTION
Typ. 420W
Max. 620W
BTU (British Thermal Unit) 1434 BTU/Hr (Typ.), 2117 BTU/Hr (Max.)
Smart Energy Saving (70%) 294W
DPM 0.5W
Power off 0.5W
SOUND
Speaker (Built-in) YES (10W x 2)
CERTIFICATION
Safety CB / NRTL
EMC FCC Class "A" / CE / KC
ERP / Energy Star YES (NewErP) / NO
ePEAT (US only) NO
OPS COMPATIBILITY
OPS Type compatible NO
OPS Power Built-in NO
SOFTWARE COMPATIBILITY
SuperSign CMS YES
SuperSign Control+ YES
SuperSign WB YES
SuperSign Cloud YES
Promota YES (Not available for EU/CIS)
Mobile CMS YES
Connected Care YES
LANGUAGE
OSD English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Türkçe, Arabic
ACCESSORY
Basic Remote Controller (include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, EYE Bolt
Optional NO
SPECIAL FEATURE
Overlay Touch Compatibility N/A
Smart Calibration N/A
Tilt (Face up) N/A
Tilt (Face down) N/A
IP Rating N/A
Conformal Coating (Power Board) YES
Power Protection N/A
Direct Sunlight N/A
