Sku: 98UH5J-H
Brand: LG
Category: Commercial Panel
Availability: On Order
On Order - These items are sourced upon request and may take longer to deliver. We will confirm availability once your order is received, as some products may occasionally be discontinued or unavailable.
Shipping Calculator
Find
We Accept
Manufacture # LG | Model # 98UH5J-H
With a great brightness of 700 nits, the UH5J-H series delivers content that can attract attention of viewers and is a suitable display solution for outdoor visibility such as airports, retail, shopping malls etc.
Features:
Overview:
Manufacturer Warranty: 03 Years Limited Warranty
| PANEL | |
| Screen Size (Inch) | 98 |
| Panel Technology | IPS |
| Back Light Type | Direct |
| Aspect Ratio | 16:9 |
| Native Resolution | 3840 x 2160 (UHD) |
| Refresh Rate | 60Hz |
| Brightness | 500nit (Typ.) |
| Contrast Ratio | 1,200:1 |
| Dynamic CR | 1,000,000:1 |
| Color Gamut | BT709 95% |
| Viewing Angle (H x V) | 178º x 178º |
| Color Depth (Number of Colors) | 1.07 Billion colors |
| Response Time | 8ms (G to G) |
| Surface Treatment (Haze) | Haze 28% |
| Life time | 50,000Hrs (Typ.) |
| Operation Hours (Hours/Day) | 24/7 |
| Portrait / Landscape | YES / YES |
| Transparency | N/A |
| QWP (Quarter Wave Plate) | N/A |
| CONNECTIVITY | |
| HDMI In | YES (3ea) |
| HDMI In (HDCP Ver.) | 2.2/1.4 |
| DP In | YES (HDCP 2.2/1.3) |
| DVI-D In | YES (HDCP 1.4) |
| RGB In | NO |
| Audio In | YES |
| RS232C In | YES |
| RJ45(LAN) In | YES (1ea) |
| IR In | YES |
| USB In | USB2.0 Type A (1ea) |
| HDMI Out | YES |
| DP Out | NO |
| Audio Out | YES |
| Touch USB | NO |
| External Speaker Out | NO |
| RS232C Out | YES |
| RJ45(LAN) Out | NO |
| IR Out | NO |
| Daisy Chain | Input: HDMI, DP / Output: HDMI |
| MECHANICAL SPECIFICATION | |
| Bezel Color | Black |
| Bezel Width | Even bezel: 14.9mm |
| Weight (Head) | 66Kg |
| Weight (Head+Stand) | N/A |
| Packed Weight | 99Kg |
| Monitor Dimensions (W x H x D) | 2191.8 x 1246.8 x 86.1mm (without Handle and LG Logo) |
| Monitor Dimension with Stand | N/A |
| Carton Dimensions (W x H x D) | 2342 x 1386 x 420mm |
| Handle | YES |
| VESA Standard Mount Interface | 800 x 400 mm |
| FEATURE - HARDWARE | |
| Internal Memory (eMMC) | 16GB |
| Wi-Fi/BT (Built-in) | YES |
| Temperature Sensor | YES |
| Auto Brightness Sensor | YES |
| Pixel Sensor | NO |
| Proximity Sensor | NO |
| Current Sensor | NO |
| BLU Sensor | NO |
| Humidity Sensor | NO |
| Acceleration (Gyro) Sensor | YES |
| Power Indicator | NO |
| Local Key Operation | YES |
| FAN (Built-in) | NO |
| FEATURE - SOFTWARE | |
| OS Ver. (webOS) | webOS 6.0 |
| Local Contents Scheduling | YES |
| Group Manager | YES |
| USB Plug & Play | YES |
| Fail over | YES |
| Booting Logo Image | YES |
| No Signal Image | YES |
| RS232C Sync | YES |
| Local Network Sync | YES |
| Backlight Sync | NO |
| PIP | YES |
| PBP | YES (4PBP) |
| Screen Share | YES |
| Video Tag | YES (4 Video Tag) |
| Play via URL | YES |
| Screen Rotation | YES |
| External Input Rotation | YES |
| Gapless Playback | YES |
| Tile Mode Setting | YES |
| Setting Data Cloning | YES |
| SNMP | YES |
| ISM Method | YES |
| Auto Set ID | YES |
| Status Mailing | YES |
| Control Manager | YES |
| Cisco Certification | YES |
| Crestron Connected | YES |
| Smart Energy Saving | YES |
| PM mode | YES |
| Wake on LAN | YES |
| Network Ready | YES |
| Beacon | YES |
| HDMI-CEC | YES |
| SI Server Setting | YES |
| webRTC | YES |
| Pro
|
YES |
| Brightness Compensation | NO |
| W/B Setting by Grey scale | NO |
| Scan Inversion | NO |
| ENVIRONMENT CONDITIONS | |
| Operation Temperature | 0 °C to 40 °C |
| Operation Humidity | 10 % to 80 % |
| POWER | |
| Power Supply | AC 100-240V~, 50/60Hz |
| Power Type | Built-in Power |
| POWER CONSUMPTION | |
| Typ. | 420W |
| Max. | 620W |
| BTU (British Thermal Unit) | 1434 BTU/Hr (Typ.), 2117 BTU/Hr (Max.) |
| Smart Energy Saving (70%) | 294W |
| DPM | 0.5W |
| Power off | 0.5W |
| SOUND | |
| Speaker (Built-in) | YES (10W x 2) |
| CERTIFICATION | |
| Safety | CB / NRTL |
| EMC | FCC Class "A" / CE / KC |
| ERP / Energy Star | YES (NewErP) / NO |
| ePEAT (US only) | NO |
| OPS COMPATIBILITY | |
| OPS Type compatible | NO |
| OPS Power Built-in | NO |
| SOFTWARE COMPATIBILITY | |
| SuperSign CMS | YES |
| SuperSign Control+ | YES |
| SuperSign WB | YES |
| SuperSign Cloud | YES |
| Promota | YES (Not available for EU/CIS) |
| Mobile CMS | YES |
| Connected Care | YES |
| LANGUAGE | |
| OSD | English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Türkçe, Arabic |
| ACCESSORY | |
| Basic | Remote Controller (include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, EYE Bolt |
| Optional | NO |
| SPECIAL FEATURE | |
| Overlay Touch Compatibility | N/A |
| Smart Calibration | N/A |
| Tilt (Face up) | N/A |
| Tilt (Face down) | N/A |
| IP Rating | N/A |
| Conformal Coating (Power Board) | YES |
| Power Protection | N/A |
| Direct Sunlight | N/A |
