| Camera :- |
|
| Image Sensor |
1/2.8”3Megapixel progressive CMOS |
| Max. Resolution |
2048 (H) × 1536 (V) |
| ROM |
4 GB |
| RAM |
2 GB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.005 [email protected] (Color,30IRE)
0.0005 [email protected] (B/W,30IRE)
0 Lux (Illuminator on) |
| S/N Ratio |
>56 dB |
| Illumination Distance |
20 m (IR) (65.6 ft) (IR LED) |
| Illuminator On/Off Control |
Auto/Manual |
| Illuminator Number |
1 (IR LED) |
| Pan/Tilt/Rotation Range |
Tilt: 0°–70° |
| Lens :- |
|
| Lens Typ |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
2.8 mm: F1.6
3.6 mm: F1.6 |
| Field of View |
2.8 mm: Horizontal 96° × Vertical 70° × Diagonal 128°
3.6 mm: Horizontal 79° × Vertical 57° × Diagonal 104° |
| Iris Type |
Fixed |
| Close Focus Distance |
2.8 mm: 0.7 m (2.3 ft)
3.6 mm: 1.3 m (4.3 ft) |
| DORI Distance |
Lens | Detect | Observe | Recognize | Identify
2.8mm | 44.8 m | 17.9 m | 9.0 m | 4.5 m
3.6mm | 64.0 m | 25.6 m | 12.8 m | 6.4 m |
| Smart Event :- |
|
| IVS |
Abandoned object; missing object |
| Professional, intelligent :- |
|
| IVS (Perimeter Protection) |
Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human), loitering detection, people gathering, parking detection |
| Face Detection |
Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 5 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, surprise), mask, beard; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting |
| People Counting |
Support tripwire number counting; people counting in area, and displaying and outputting yearly/monthly/daily reports. |
| Support queue management, and displaying and outputting yearly/monthly/daily reports. |
Support 4 tripwire rule configuration, people counting in 4 areas, and 4 queue managements. |
| Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Video :- |
|
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.264+
Smart H.265+ |
| Video Frame Rate |
Main stream: 3MP (1–25/30 fps)
Sub stream: D1 (1–25/30 fps)
Third stream: 2MP (1–25/30 fps)
Fourth stream: 2MP (1–25/30 fps)
Fifth stream: D1 (1–25/30 fps) |
| Stream Capability |
5 streams |
| Resolution |
3M (2048 × 1536); 1080p (1920 × 1080); 720p ( 1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240); 640 × 480 (VGA) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 3 kbps–17664 kbps
H.265: 3 kbps–17664 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
DWDR |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Devotional |
Yes |
| Privacy Masking |
4 areas |
| Audio :- |
|
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; G.726; G.723 |
| Built-in Speaker |
Yes |
| Alarm :- |
|
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; external alarm; face detection; people counting in area; stay alarm; people counting; people counting exception detection; safety exception |
| Network :- |
|
| Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP; Bonjour |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P; RTMP |
| User/Host |
20 |
| Storage |
FTP; SFTP; Micro SD card (support max. 256 G); NAS |
| Browser |
IE9; IE11; FireFox; Chrome |
| Management Software |
Smart PSS; DSS; NVR; IVSS |
| Mobile Phone |
IOS; Android |
| Port :- |
|
| RS-485 |
1 (baud rate range: 1200 bps–115200 bps) |
| Audio Input |
2 channels (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
2 channels in: 5mA 3V–5V DC |
| Alarm Output |
2 channels out: 1,000mA 30V DC/500mA 50V DC |
| Power :- |
|
| Power Supply |
12V DC/PoE; ePoE |
| Power Consumption |
Basic power consumption: 3.5W (12V DC); 4.4W (PoE)
Max. power consumption (ICR switch + IR full intensity + WDR + Intelligent functions enabled): 9.1W (12V DC); 10.6W (PoE) |
| Environment :- |
|
| Operating Conditions |
-40°C to +60°C/Less than 95% RH |
| Storage Temperature |
–40°C to +60°C (–40°F to +140°F) |
| Ingress Protection |
IP67; IK10 |
| Structure :- |
|
| Casing |
Metal |
| Dimensions (L × W × H) |
204.0 mm × 78.0 mm × 61.5 mm |
| Net Weight |
0.81 kg (1.8 lb) |
| Gross Weight |
1.19 kg (2.6 lb) |
