Dahua 6 MP IR Fixed-focal Bullet WizSense Network Camera

SKU : DH-IPC-HFW3666EP-AS-AUS
Brand : Dahua
Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse
Explore Dahua WizSense Series AI security cameras with 6MP resolution, Smart Motion Detection Plus (SMD+), and Starlight technology for clear, accurate monitoring in low light. Featuring advanced human and vehicle detection, it reduces false alarms and provides smart, simple, and affordable security solutions.
Ask a question about this product
$172.00

Estimated Shipping

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture: Dahua | Model: DH-IPC-HFW3666EP-AS-AUS



Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chips and deep learning algorithms. It focuses on humans and vehicles with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.
SMD 4.0
Dahua Smart Motion Detection technology works with intelligent algorithms to classify targets that trigger motion detection alarms. It filters out objects that are not targeted, such as small and large animals, to avoid triggering false alarms. With an AI NVR, Quick Pick technology becomes available, allowing you to easily search for and pick out human and vehicle targets from SMD event videos, prioritizing the highest matches.
WizSense Series - Engineered to provide smart, simple and affordable security. WizSense series cameras support an independent AI chip with a deep learning algorithm to provide a more intelligent and simple security solution focused on human and vehicle detection. This helps filter out false alerts triggered by bugs, changes in light, leaves, trees and animals.
Supports Smart Motion Detection Plus (SMD+) dramatically reduces false alarms in motion detection by only detecting humans and vehicles, greatly reducing false alerts triggered by bugs, changes in light, leaves, trees and animals. Target is tracked and triggers real-time alerts to a smart device through the iOS/Android app.
Through advanced video algorithms, Dahua's Intelligent Video Surveillance (IVS) technology supports smart functions such as Tripwire and Intrusion Detection.
Starlight technology generates clear images in near-complete darkness. A high-performing sensor and special algorithms work together to capture images in low-light and no-light environments.



Key Features



  • 6-MP 1/2.7" CMOS image sensor, excellent low luminance performance and high definition of images.
  • Outputs max. 6 MP (3072 × 2048) @25/30 fps.
  • H.265 codec, high compression rate, ultra-low bit rate.
  • Built-in IR LED, max. IR distance: 30 m.
  • ROI, SMART H.264 +/H.265+, AI H.264/H.265. Flexible coding, applicable to various bandwidth and storage environments.
  • Rotation mode, WDR, 3D NR, HLC, BLC, and digital watermarking, applicable to various monitoring scenes.
  • Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
  • Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
  • Alarm: 1 in, 1 out (Only - AS supports); audio: 1 in, 1 out (Only - AS supports); max. 256 G Micro SD card. Built-in Mic.
  • 12 VDC/PoE power supply, easy for installation.
  • IP67 protection.
  • SMD 4.0, AI SSA.

Technical Specifications

Image Sensor 1/2.7" CMOS
Max. Resolution 3072 (H) × 2048 (V)
ROM 128 MB
RAM 512 MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination 0.005 [email protected] (Color, 30 IRE)
0.0005 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio >56 dB
Illumination Distance 30 m (98.43 ft)
Illuminator On/Off Control Auto/Manual
Illuminator Number 1 (IR LED)
Pan/Tilt/Rotation Range Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360°
Lens Type Fixed-focal
Lens Mount M12
Focal Length 2.8 mm; 3.6 mm
Max. Aperture F1.4
Field of View 2.8 mm: Horizontal: 111°; Vertical: 58°; Diagonal: 132°
3.6 mm: Horizontal: 92°; Vertical: 45°; Diagonal: 110°
Iris Control Fixed
Close Focus Distance 2.8 mm: 1.1 m (3.61 ft)
3.6 mm: 1.7 m (18.37 ft)
IVS (Perimeter Protection) Tripwire, intrusion (support classification and accurate detection of vehicle and human)
AI SSA Yes
Quick Pick With AI NVR, quickly pick up human/vehicle targets from SMD events
Smart Search Works with Smart NVR for intelligent search and event extraction
BLC Yes
HLC Yes
WDR 120 dB
Scene Self-adaptation (SSA) Yes
White Balance Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control Auto
Noise Reduction 3D NR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Defog Yes
AFSA Yes
Image Rotation 0°/90°/180°/270°
Mirror Yes
Privacy Masking 4 areas
Built-in MIC Yes
Audio Compression G.711a; G.711Mu; PCM; G.726; G.723
Network Port RJ-45 (10/100 Base-T)
SDK and API Yes
Network Protocol IPv4, IPv6, HTTP, TCP, UDP, RTP, RTSP, RTCP, RTMP, FTP, SFTP, DHCP, DNS, DDNS, QoS
Cyber Security Video encryption, Firmware encryption, Security logs, IP/MAC filtering, HTTPS
Interoperability ONVIF (Profile S/G/T), CGI, P2P, Milestone, Genetec
User/Host 20 (Total bandwidth: 64 M)
Storage FTP, SFTP, Micro SD card (max. 256G), NAS
Power Supply 12 VDC/PoE (802.3af)
Power Consumption Basic: 3.1 W (12 VDC); 3.7 W (PoE)
Max: 5.3 W (12 VDC); 6.5 W (PoE)
Operating Temperature –40 °C to +60 °C (–40 °F to 140 °F) / Less than 95% RH
Storage Temperature –40 °C to +60 °C (–40 °F to 140 °F)
Protection IP67
Casing Metal
Product Dimensions 192.7 mm × 70.5 mm × 66.4 mm (7.59" × 2.77" × 2.61")
Net Weight 590 g (1.30 lb)
Gross Weight 780 g (1.72 lb)
