LCD panel type |
IPS technology |
Backlight type |
W-LED system |
Panel Size |
23.8 inch/60.5 cm |
Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
Effective viewing area |
527.04 (H) x 296.46 (V) |
Aspect ratio |
16:9 |
Maximum resolution |
1920 x 1080 @ 75 Hz |
Pixel Density |
93 PPI |
Response time (typical) |
4 ms (Grey to Grey)* |
Brightness |
300 cd/m² |
Contrast ratio (typical) |
1000:1 |
SmartContrast |
50,000,000:1 |
Pixel pitch |
0.2745 x 0.2745 mm |
Viewing angle |
78º (H)/178º (V)
@ C/R > 10 |
Flicker-free |
Yes |
Picture enhancement |
SmartImage |
Display colour |
16.7 M (8 bit) |
Colour gamut (typical) |
NTSC 88%*, sRGB 105%* |
Scanning Frequency |
30–85 kHz (H) / 48–75 Hz (V) |
sRGB |
Yes |
LowBlue Mode |
Yes |
EasyRead |
Yes |
Signal Inpu |
HDMI 1.4 x 1, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD up to 90 W) |
HDCP |
HDCP 1.4 (HDMI/DisplayPort/USB-C); HDCP 2.2 (HDMI/DisplayPort/USB-C) |
HBR3 |
HBR 3 (DisplayPort, USB-C) |
Signal Output |
DisplayPort out x 1 |
USB Hub |
USB 3.2, Gen 2/10 Gbps, USB-C upstream x 1 (Data), USB-A downstream x 4 (with 1 for fast charge B.C 1.2), USB-C downstream x 1 (Data, PD 15 W) |
Audio (In/Out) |
Audio out/Microphone in combo jack |
RJ45 |
Ethernet LAN up to 1 G*, Wake on LAN |
Sync Input |
Separate Sync |
Version |
USB PD version 3.0 |
Max power delivery |
USB-C up to 90 W (5 V/3 A, 7 V/3 A, 9 V/3 A, 10 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/4.5 A) |
Built-in Speakers |
5 W x 2 |
Built-in webca |
Pop-up 5.0 megapixel camera with a microphone and LED indicator (for Windows Hello) |
Noise cancellation |
Yes |
MultiView |
PIP/PBP mode
2 x devices |
KVM |
Yes (USB-C/USB-C) |
User convenience |
SmartImage
Input
User
Menu Power On/Off |
Control software |
SmartControl |
Other convenience |
Kensington lock
VESA mount (100 x 100 mm) |
Plug and Play Compatibility |
DDC/CI
Mac OS X
sRGB
Windows 11 / 10 / 8.1 / 8 / 7 |
Height adjustment |
150 mm |
Pivot |
-/+90 degree |
Swivel |
-/+ 180 degree |
Tilt |
-5/30 degree |
On mode |
15.3 W (typ.) (EnergyStar test method) |
Standby mode |
0.3 W (typ.) |
Off mode |
Zero watts with AC switch |
Energy Label Class |
E |
Power LED indicator |
Operation - White
Standby mode - White (flashing) |
Power supply |
Built-in
100–240 VAC, 50–60 Hz |
Product with stand (max height) |
540 x 500 x 205 mm |
Product without stand (mm) |
540 x 323 x 51 mm |
Product with stand (kg) |
5.50 kg |
Product without stand (kg) |
3.90 kg |
Temperature range (operation) |
0°C to 40* °C |
Temperature range (storage) |
-20°C to 60 °C |
Relative humidity |
20%-80 % |
Altitude |
Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m) |
MTBF (demonstrated) |
70,000 hrs (excluded backlight) |
Environmental and energy |
PowerSensor
LightSensor
EnergyStar 8.0
EPEAT*
TCO Certified Edge
RoHS |
Recyclable packaging material |
1 |
Post-consumer recycled plastic |
0.85 |
Specific Substances |
Mercury free
PVC/BFR free housing |
Front bezel |
Black |
Rear cover |
Black |
Foot |
Black |
Finish |
Texture |
Monitor with stand |
Yes |
Cable |
HDMI cable, DisplayPort cable, USB-C to C/A Y cable, Power cable |
User Documentation |
Yes |
