Asus Mini PC PN52 AMD Ryzen 7 5700H Barebone Kit

SKU : PN52-R7BAREBONES
Brand : Asus
Availablity : Online Only, In Stock
Ships within 1 and 3 days from our Seven Hills, NSW warehouse
Processor: AMD Ryzen 7, Memory: 32 GB, Graphics: AMD Radeon Graphics, Wi-Fi: Wi-Fi 6E (802.11ax), Warranty: 03 Years, PN52-R7BAREBONES.
Ask a question about this product
$707.00

Estimated Shipping

Pay what you see.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Asus | Model # PN52-R7BAREBONES



ASUS ExpertCenter PN52 is well-equipped for a wide range of functions and can be used for digital signage, POS systems or intelligent vending machines. The configurable port can be specified with either HDMI, VGA, DisplayPort, or COM ports, as well as 2.5GbE LAN, for monitors or legacy devices such as barcode scanners or receipt printers.



Features:

  • ASUS ExpertCenter PN52 gets a significant graphical boost with Radeon Graphics to deliver crisp, clear visuals that are way ahead of its class. It delivers a marked improvement, raising its score from 14.4% in 3DMark11 to 23.6% in the 3DMark Night Raid performance benchmarks.
  • ASUS ExpertCenter PN52 can support up to four 4K displays via two HDMI ports, two DisplayPort over USB-C or other user-configurable ports, without any limitation on the combination used.
  • ASUS ExpertCenter PN52 delivers breathtaking 8K visuals at 30 frames per second via the configurable standard DisplayPort or DisplayPort over USB-C. Experience a level of detail that’s 4X greater than 4K, or 16X that of traditional FHD output.
  • ASUS ExpertCenter PN52 can draw power from any USB Power Delivery-enabled display or device, eliminating the need for a separate power adapter to create a neater, uncluttered workspace.
  • An easy-access underside panel allows users replace and upgrade memory, storage and the wireless card. All that’s required is a screwdriver.
  • 2.5 Gb Ethernet provides superfast networking and data transfer speeds for efficient, productive multitasking.



Overview:

  • Processor: AMD Ryzen 7
  • Memory: 32 GB
  • Graphics: AMD Radeon Graphics
  • Wi-Fi: Wi-Fi 6E (802.11ax)



Manufacturer Warranty: 03 Year Limited Warranty

Technical Specifications

Built-in processor Yes
Processor manufacturer AMD
Processor family AMD Ryzen 7
Processor model 5800H
Processor frequency 3.3 GHz
Processor cores 8
Processor threads 16
Processor boost frequency 4.6 GHz
Processor cache 16 MB
Memory slots type SO-DIMM
Number of memory slots 2
Maximum internal memory 32 GB
Supported memory types DDR4-SDRAM
Supported storage drive types HDD & SSD
Storage drive sizes supported M.2
SSD form factor M.2
Storage drive interface PCI Express
Number of storage drives supported 3
On-board graphics card Yes
Graphics card family AMD
On-board graphics card model AMD Radeon Graphics
Discrete graphics card model Not available
Audio Realtek ALC3251 HD Audio CODEC
Wi-Fi Wi-Fi 6E (802.11ax)
Ethernet LAN Yes
Wi-Fi Yes
LAN controller Realtek RTL8125B-CG
Bluetooth 5.2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1
HDMI ports quantity 2
HDMI version 2.1
DisplayPorts quantity 1
DisplayPort version 1.4
Combo headphone/mic port Yes
Ethernet LAN (RJ-45) ports 1
DC-in jack Yes
Product colour Black
Product type Mini PC barebone
Certification BSMI/CB/CE/FCC/UL/CCC/Energy Star/C-Tick/WiFi/RF/VCCI
Trusted Platform Module (TPM) Yes
Operating system installed No
Power supply type External AC adapter
Power supply 120 W
AC adapter output voltage 19 V
AC adapter output current 6.32 A
Width 120 mm
Depth 130 mm
Height 58 mm
Weight 1 kg (include 2.5" HDD)
