Asus KFN5 AMD F 1207 8xDDR2 E-ATX Server Motherboard

Brand : Asus
Availablity : Online Only, In Stock
Ships within 1 and 3 days from our Seven Hills, NSW warehouse
Processor / System Bus: 2 AMD Opteron 2000 Series processors, Core Logic: nVIDIA nForce Professional 3600 MCP, Form Factor: 12.0" * 10.5", Memory Capacity: Maximum up to 32GB, Warranty: 02 Years, KFN5-D SLI.
Ask a question about this product

Estimated Shipping

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa


  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Asus | Model # KFN5-D SLI


The KFN5-D SLI targets the enthusiast crowd by offering excellent graphics capability with the SLI-ready, dual-PCI-E x16 platform. Running on the Nvidia nForce Professional 3600chipset, the KFN5-D SLI offers eight DIMM slots to support dual-channel DDR2-533/667 up to 32GB.



  • Support Dual AMD Socket F processors, with Dual-core ready and 64bit operating system. 2 CPU Sockets provide almost 4 CPU performance.
  • Support up to 8 DIMM, 32GB DDRII 533/ 667 ECC Registered memory space. DDRII 533/ 667 provides better performance over last generation Opteron DDR 400 platform.
  • Highly memeory capacity to meet your critical computing environment needs.
  • NVIDIA SLI technology revolutionizes graphic performance by combining multiple PCI Express GPUs in a single and scalable system.
  • Dual GPUs provide increased, supercharged 3D graphics and performance.
  • Dual PCI-E Gb LAN feature moves network data more efficiently.
  • Teaming and fail over function provide more flexible and reliable server connectivity.
  • Build-in MCP55 Pro provides 6 SATAII ports supporting RAID 0, 1, 0 + 1, 5, and JBOD.
  • On board Sil3132 SATA controller provides 2 SATAII ports, supporting RAID 0, 1.



  • Processor / System Bus: 2 AMD Opteron 2000 Series processors
  • Core Logic: nVIDIA nForce Professional 3600 MCP
  • Form Factor: 12.0" * 10.5"
  • Memory Capacity: Maximum up to 32GB

Manufacturer Warranty: 02 Years Limited Warranty

Technical Specifications

Processor / System Bus 2 AMD Opteron 2000 Series processors
Core Logic nVIDIA nForce Professional 3600 MCP
Form Factor 12.0" * 10.5"
Chassis Support N/A
ASUS Features Smart Fan: Smart Fan II
Rack Ready (Rack and Pedestal dual use): Yes
ASWM2.0: Yes
Memory Total Slots: 8
Capacity: Maximum up to 32GB
Memory Type: Dual Channel ECC Reg. DDR2 533/ 667
Memory Size: 512 MB, 1 GB, 2GB
Expansion Slots (follow SSI Location #) Total Slots: 4 (base on SSI)
Slot 1: 1 * 32bit / 33MHz PCI
Slot 2: 1 * PCI-E x 16 (x8 link)
Slot 3: 1 * PCI-E x 1
Slot 4: 1 * PCI-E x 16
Storage IDE Controller:
IDE: Dual Channels Bus Master IDE support UltraATA 100 / 133

SATA Controller:
MCP55 Pro:
6 SATAI/II ports, RAID 0, 1, 0+1, 5, JBOD

2 SATAI /II ports, RAID 0, 1
Networking LAN: 2 x Broadcom BCM5754 PCI-E Gb LAN
Graphic N/A
Onboard I/O Connectors Floppy Connector: 1
PSU Connector: SSI 24-pin + SSI 8-pin
USB Connectors: 3
Fan Header: 6 * Fan
SMBus: 1 * SMbus
Game Port: 1
Rear I/O Connectors External Serial Port: 1
External USB Port: 4
IEEE1394: 1 * IEEE1394 (optional)
Mic/Line-in/Line-out: 1
RJ-45: 2
PS/2 KB/Mouse: 1
S/P DIF Out:
1 * Optical SPDIF output
1 * Coaxial SPDIF output
Management Solution Software: ASWM2.0
Monitoring CPU Temperature: V
Safety N/A
EMI US (FCC, CFR47 Part 15, Class B)
Europe (CE, EN55022 & EN55024)
Anti-virus Software N/A
OS Support N/A
Environment Operation temperature: 10 to 35
Non operation temperature: -40 to 70
Non operation humidity: 20% ~ 90% ( Non condensing)
Optional Items N/A
Product SKUs N/A
