Winstar Wireless AC1300M Dual Band USB 3.0 Adapter

Sku: USBWIN688U3

Availability: In Stock

Brand: Winstars

Category: Wireless Adapters

$30.80

Shipping Calculator

Find

Color: Silver, Ports: USB 3.0, Button: WPS, Power Supply: USB 5V, Frequency band: 5GHz and 2.4GHz, 01 Year Limited Warranty, USBWIN688U3.

-
+

100% Guarantee Safe Checkout

Thumbnail 3

Description

Manufacture # Winstars | Model # USBWIN688U3



The Winstar Wireless AC1300M Dual Band USB 3.0 Adapter is a high-speed wireless adapter that supports the latest 802.11ac Wi-Fi standard. It can deliver speeds of up to 1300 Mbps, making it ideal for streaming HD videos, playing online games, and downloading large files.



Features:

  • 1300 (867+400)Mbps wireless speed
  • Support 2.4GHz & 5GHz WLAN networks
  • Dual Band connections for lag-free HD video streaming and gaming
  • SuperSpeed USB 3.0 port, backward compatible to USB 2.0
  • Complies with IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b standards
  • 20MHz & 40MHz & 80MHz bandwidth transmission
  • OFDM with BPSK, QPSK, 16QAM, 64QAM, 256QAMmodulation
  • Supports Windows XP / Vista / 7 / 8 / 8.1/10, MAC


Overview:

  • Color: Silver
  • Ports: USB 3.0
  • Button: WPS
  • Power Supply: USB 5V
  • Frequency band: 5GHz and 2.4GHz



Manufacturer Warranty: 01 Year Limited Warranty

Color Silver
Ports USB 3.0
Button WPS
LED 1 X Link/ Active
Chipset RTL8812AU
Power Supply USB 5V
Power Plug N/A
Rated Voltage/ requency /current DC 5V about 500mA
Wireless Standard:IEEE802.11ac,IEEE 802.11a, IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
Modulation: 11ac\n: 16QAM, 64QAM 128QAM 256QAM with OFDM
11g: BPSK, QPSK, 16QAM, 64QAM, OFDM
11b: DQPSK, DBPSK, DSSS, CCK
Speed 802.11ac: up to 867Mbps
802.11n: up to 400Mbps
802.11a: up to 54Mbps
802.11g: 54 M
802.11b: 11 M
Frequency band 5GHz and 2.4GHz
Power 802.11b: 22dBm ± 2 dBm 802.11g: 16dBm ± 2 dBm
802.11n: 15dBm ± 2 dBm 802.11ac: 14dBm ± 2 dBm
Operating Temperature 0ºC~40ºC
Storage Temperature -10~70ºC
Relative Humidity(Operational): 10%~90%,noncondensing
Relative Humidity(Storage) 10%~90%,noncondensing
Item Weight 0.25 KG
Product Dimensions 98mm L x 28mm W x 10mm (L x W x H)
Package content 1 x Wireless-AC USB3.0 Aapter
1 x Quick Installation
1 x CD driver
