Sku: USW-Pro-8-PoE
Brand: Ubiquiti
Category: Switches
Availability: In Stock
Ships in 1-2 days.
Pickup from Seven Hills in 1-2 days.
Shipping Calculator
Find
Enclosure materials: Polycarbonate, metal, Mount material: Polycarbonate, Management interface: Ethernet In-Band, Networking interface: (8) GbE RJ45 ports, (2) 10G SFP+ ports, Total non-blocking throughput: 28 Gbps, Switching capacity: 56 Gbps, LCM display: (1) 1.3" touchscreen, LEDs: RJ45 ports: link/activity, Warranty: 01 Year, USW-Pro-8-PoE.
We Accept
Manufacture # Ubiquiti | Model # USW-Pro-8-PoE
The Ubiquiti USW-Pro-8-PoE is an 8-port managed Layer 3 Gigabit switch with PoE+ and PoE++ output designed for small businesses and home users who need a powerful and versatile switch for their network.
Features:
Overview:
Manufacturer Warranty: 01 Year Limited Warranty
| Mechanical :- | |
| Dimensions | 200 x 248 x 44 mm (7.9 x 9.8 x 1.7") |
| Weight | 2.1 kg (4.6 lb) |
| Enclosure materials | Polycarbonate, metal |
| Mount material | Polycarbonate |
| Hardware :- | |
| Management interface | Ethernet In-Band |
| Networking interface | (8) GbE RJ45 ports (2) 10G SFP+ ports |
| PoE interface | (6) PoE/PoE+ (Pins 1, 2+; 3, 6-) (2) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) |
| Total non-blocking throughput | 28 Gbps |
| Switching capacity | 56 Gbps |
| Power method | Universal input, 100-240V AC, 2A Max. |
| Power supply | AC/DC, internal |
| Supported voltage range | 100-240V AC |
| Max. power consumption | 30W (Excluding PoE output) |
| Total available PoE | 120W |
| Max. PoE wattage per port by PSE | PoE: 15W PoE+: 30W PoE++: 60W |
| Voltage range PoE mode | PoE: 44-57V PoE+: 50-57V PoE++: 50-57V |
| LCM display | (1) 1.3" touchscreen |
| LEDs | RJ45 ports: link/activity |
| Button | Factory reset |
| Ambient operating temperature | -5 to 45° C (23 to 113° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| Switching Features :- | |
| Layer 2 features | IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs |
| Layer 3 features | DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks |
| Application Requirements :- | |
| UniFi Network | Version 7.5.176 and later |
