Sku: LOCO5AC
Brand: Ubiquiti
Category: Routers-Gateways
Availability: In Stock
Ships in 1-2 days.
Pickup from Seven Hills in 1-2 days.
Shipping Calculator
Find
Enclosure material: UV-stabilized plastic, Mounting: Pole mounting kit, Power supply: 24V, 0.3A Gigabit PoE supply, Supported voltage range: 24V ±10%, Max. power consumption: 8.5W, Gain: 13 dBi, 01 Year Limited Warranty, LOCO5AC.
We Accept
Manufacture # Ubiquiti | Model # LOCO5AC
The NanoStation AC and NanoStation AC loco take the same concept to the future with sleek form factors, along with integrated airMAX (MIMO TDMA protocol) technology and dedicated Wi-Fi management.
Features:
Overview:
Manufacturer Warranty: 01 Year Limited Warranty
| Mechanical:- | |
| Dimensions | 179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33") |
| Weight | 0.18 kg (6.35 oz) |
| Enclosure material | UV-stabilized plastic |
| Mounting | Pole mounting kit (Included) |
| Hardware:- | |
| Networking interface | (1) GbE RJ45 port |
| Power method | Passive PoE 2-Pair (Pairs 4, 5+; 7, 8 Return) |
| Power supply | 24V, 0.3A Gigabit PoE supply |
| Supported voltage range | 24V ±10% |
| Max. power consumption | 8.5W |
| LEDs | Power, Ethernet, (4) signal strength |
| Operating temperature | -40 to 70° C (-40 to 158° F) |
| Operating humidity | 5 to 95% noncondensing |
| System:- | |
| Gain | 13 dBi |
| Channel bandwidths | 10/20/30/40/50/60/80 MHz |
| Cross-pol isolation | 20 dB min. |
| Max. VSWR | 1.8:1 |
| Beamwidth | 45° (H-pol) / 45° (V-pol) / 45° (Elevation) |
| Polarization | Dual linear |
| Operating Frequency (MHz):- | |
| Worldwide | 5150-5875 MHz |
| USA | |
| U-NII-1 | 5150-5250 MHz |
| U-NII-2A | 5250-5350 MHz |
| U-NII-2C | 5240-5725 MHz |
| U-NII-3 | 5725-5850 MHz |
| Management Radio (MHz):- | |
| Worldwide | 2412 - 2472 MHz |
| US/CA | 2412 - 2462 MHz |
