Manufacture # Ubiquiti | Model # LBE-5AC-GEN2
The LiteBeam 5AC Gen 2 directs RF energy in a tighter beamwidth. With the focus in one direction, the LiteBeam 5AC Gen 2 blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.
Features:
Overview:
Manufacturer Warranty: 01 Year Limited Warranty
| Mechanical:- | |
| Dimensions | 358 x 271.95 x 272.5 mm (14.1 x 10.7 x 10.73") |
| Weight | Without mount: 800 g (1.76 lb) With mount: 980 g (2.16 lb) |
| Wind survivability | 200 km/h (125 mph) |
| Wind loading | 275 N at 200 km/h (61.8 lbf at 125 mph) |
| Hardware:- | |
| Networking interface | (1) GbE RJ45 port |
| Power method | Passive PoE (pairs 4, 5+; 7, 8 return) |
| Power supply | 24V, 0.3A Gigabit PoE adapter (Included) |
| Max. power consumption | 7W |
| Max. power output | 25 dBm |
| Gain | 23 dBi |
| Operating temperature | -40 to 70° C (-40 to 158° F) |
| Operating humidity | 5 to 95% noncondensing |
| Operating Frequency (MHz):- | |
| Worldwide | 5150-5875 MHz |
| USA | |
| U-NII-1 | 5150-5250 MHz |
| U-NII-2A | 5250-5350 MHz |
| U-NII-2C | 5240-5725 MHz |
| U-NII-3 | 5725-5850 MHz |
| Management Radio (MHz):- | |
| Worldwide | 2412 - 2472 MHz |
| US/CA | 2412 - 2462 MHz |
