| Image Sensor |
1/2.7” Progressive Scan CMOS |
| Shutter Speed |
1/3 to 1/10000 s |
| Slow Shutter |
Yes |
| Minimum Illumination |
0.005 Lux; 0 Lux with IR/white light |
| Day/Night Mechanism |
IR Cut Filter |
| Day/Night Switch |
Day/Night/Auto/Schedule-Switch |
| LENS Type |
Fixed Focal Lens |
| Focal Length |
2.8/4 mm |
| Aperture |
2.8 mm: F1.6
4 mm: F1.6 |
| FOV (2.8 mm) |
Horizontal FOV: 109°
Vertical FOV: 57°
Diagonal FOV: 128° |
| FOV (4 mm) |
Horizontal FOV: 90°
Vertical FOV: 48°
Diagonal FOV: 107° |
| Lens Mount |
M12*P 0.5 |
| DORI Distance (2.8 mm) |
Detect: 64 m (209 ft)
Observe: 27 m (87 ft)
Recognize: 13 m (42 ft)
Identify: 6 m (21 ft) |
| DORI Distance (4 mm) |
Detect: 80 m (262 ft)
Observe: 33 m (109 ft)
Recognize: 16 m (52 ft)
Identify: 8 m (26 ft) |
| Angle Adjustment |
Manual: Pan: 0° to 360°, Tilt: 0° to 85° |
| ILLUMINATOR (IR LED) |
Quantity: 2
Range: 30m
Wavelength: 850nm |
| ILLUMINATOR (White LED) |
Quantity: 2
Range: 30m |
| Illuminator On/Off Control |
Auto/Scheduled/Always on/Always off |
| VIDEO |
Max. Resolution: 2880 X 1620 |
| Main Stream |
Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
| Main Stream Resolution |
2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080, 1280x720 |
| Sub-Stream |
Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
| Sub-Stream Resolution |
704x576, 640x480, 352x288, 320x240 |
| Bit Rate Control |
CBR, VBR |
| Video Compression |
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264 |
| Image Settings |
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software |
| Image Enhancement |
BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range |
120 dB |
| SNR |
≥ 52 dB |
| Image Parameters Switch |
Yes |
| Privacy Mask |
Up to 4 Masks |
| ROI |
1 Region |
| OSD Setting |
Yes |
| AUDIO |
Audio Communication: Two-Way Audio
Audio Input: Yes
Audio Output: Yes
Audio Compression: Yes
Audio Sampling Rate: 8KHz
Environment Noise Filtering: Yes
Audio Bit Rate: 64 Kbps (G.711 alaw) |
| NETWORK |
Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
ONVIF: Yes
API: Open Network Video Interface (Profile S)
Simultaneous Live View: 3 Main Streams & 3 Sub-Streams
Client: VIGI App, VIGI Security Manager, Web UI
Web Browser: Google Chrome® 57 and above, Firefox® 52 and above, Safari® 11 and above, Microsoft® Edge 91 and above |
| Cloud |
Yes |
| Security |
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| ALARM AND EVENT MANAGEMENT |
Smart Event: Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection
Basic Event: Motion Detection, Video Tampering Detection, Exception (Illegal Login), Scene Change Detection |
| Alarm Linkage |
Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing |
| Linkage Method |
N/A |
| Output Notification |
Message Push |
| Deep Learning Function |
People & Vehicle Analytics, Multi-Target-Type Detection |
| INTERFACES |
Network Interface: 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Alarm: N/A
Reset Button: Yes
Power: DC Power Port
On-board Storage: Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB
Built-in Microphone: Yes; Records within a 15-ft Radius of the Camera
Built-in Speaker: Yes |
| GENERAL |
Operating Temperature: -30–60 °C
Storage Temperature: -40–60 °C
Operating Humidity: 95% or Less (Non-Condensing)
Storage Humidity: 95% or Less (Non-Condensing)
Material: Plastic
Net Weight: 0.24 Kg
Gross Weight: 0.4 Kg
Power Supply: 12V DC ± 5%, Max. 9 W, 5.5mm Coaxial Power Plug
PoE: 802.3af/at, class 0, Max. 10.5 W
Protection: N/A
Product Dimensions (L x W x H): Φ123x84 mm
Certifications: CE, NTRA, VCCI, KC, BSMI, FCC, IC |
