TP-LINK 16-port Gigabit Desktop/rackmount TL-SG1016PE

Availablity In stock
TP-Link TL-SG1016PE 16-Port Gigabit Desktop/Rackmount Switch With 16-Port PoE+

Ask a question about this product

Product Description



What This Product Does

The TL-SG1016PE is an 16-Port Gigabit Desktop/Rack mountable Switch with all 16 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 124W up to 30W per port TL-SG1016PE can power more high-powered devices such as wireless Access Points (APs) IP Cameras or IP Phones. Moreover with innovative energy-efficient technology the TL-SG1016PE can save up to 75% of the power consumption making it an eco-friendly solution for your business network.

How This Product Works

All 16 ports of TL-SG1016PE support Power over Ethernet Plus (PoE+) standard which can automatically detect and supply power to any IEEE 802.3af/at compliant device(s). In this situation the electrical power is transmitted along with data in a single cable allowing you to expand your network where there are electrical cables or outlets where you wish to fix devices such as APs IP Cameras or IP Phones.

Overload Arrangement

TL-SG1016PE has a priority function which helps protect the system when its power is overloaded. If all PoE+ devices' power consumption is greater than or equal to 124W a priority will be arranged among the 16 PoE+ ports at which point the system will cut off the power of the lowest-priority port.

Port Priority Function

*Priority (port 1 > port 2 > port 3 > port 4 > port 5 > port 6 > port F > port 8): This function helps protect the system if the power becomes overloaded. For example if port 1 2 4 and 7 are using 30W (maximum power per port is 30W the system power is 120W in total) and there is an additional device inserted into Port 3 at 25W the system will cut off the power of Port 7 in response to the power exceeding the 120W limit. This means Port 1 2 and 4 will use 30W and Port 3 will use 25W with no power will be supplied to Port 7 as it has the lowest designated priority among the ports in use.

Easy To Use

TL-SG1016PE is easy to install and use. It requires no configuration or installation. With its Desktop/Rack mountable design outstanding performance and quality the TP-LINK TL-SG1016PE 16-Port Gigabit Desktop/Rack mountable Switch with 16-Port PoE is a great choice for expanding your home or office network.



  • Interface:
    • 16 10/100/1000Mbps RJ45 Ports
    • AUTO Negotiation/AUTO MDI/MDIX
  • Network Media:
    • 10BASE-T: UTP category 3 4 5 cable (maximum 100m)
    • EIA/TIA-568 100Ω STP (maximum 100m)
    • 100BASE-TX: UTP category 5 5e cable (maximum 100m)
    • EIA/TIA-568 100Ω STP (maximum 100m)
    • 1000BASE-T: UTP category 5 5e 6 or above cable (maximum 100m)
    • EIA/TIA-568 100Ω STP (maximum 100m)
  • Fan Quantity: 1
  • Power Supply : 100-240VAC 50/60Hz
  • Power Consumption:
    • Maximum (PoE on): 124.4W (220V/50Hz)
    • Maximum (PoE off): 14.4W (220V/50Hz)
  • PoE+ Ports(RJ45) : 8 Ports
  • Backbound Bandwidth : 32 Gbps
  • Mac Address Table : 8K
  • Buffer Size : 1.5 Mbits
  • Dimensions (W x D x H) : 11.6*7.1*1.7 in. (294*180*44 mm)


  • Transfer Method : Store-And-Forward
  • Advanced Functions : Compatible With IEEE 802.3af/at Compliant PDs
  • Priority Function:
    • Mac Address Auto-Learning And Auto-Aging
    • IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode


  • Certification: FCC CE RoHS
  • Package Contents:
    • TL-SG1016PE
    • Power Cord
    • Installation Guide
    • Rackmount Kit
    • Rubber Feet
  • Consumption:
    • 9.5 watts (max. no PD connected)
    • 140.1 watts (max. with 126w PD connected)
  • Environment:
    • Operating Temperature: 0C~40C (32F~104F)
    • Storage Temperature: -40C~70C (-40F~158F)
    • Operating Humidity: 10%~90% non-condensing
    • Storage Humidity: 5%~90% non-condensing
