Manufacture: Thermaltake | Model: PS-TRS-0550NPCWAU-2
The TRS-550AH2NK is a reliable 550W ATX power supply designed to deliver stable and efficient performance. Built with an Active PFC system, it ensures optimal power regulation while maintaining high efficiency levels between 82-86% at 20-100% load. The unit features a black chassis with a durable 120mm fan running at 1800 RPM for efficient cooling. It supports a wide operating temperature range of 5°C to 40°C and offers long-lasting performance with an MTBF of 100,000 hours. Equipped with dual PCI-E 6+2 pin connectors, it is ideal for gaming or workstation builds. Safety-certified with CE, CB, and TUV approvals, this power supply guarantees quality and reliability.
| Watts | 550W |
|---|---|
| RGB Fan | No |
| Form Factor | ATX |
| Model | TRS-550AH2NK |
| Type | Intel ATX 12V 2.3 |
| Max. Output Capacity | 550W |
| Colour | Black |
| PFC (Power Factor Correction) | Active PFC |
| Power Good Signal | 100-500 msec |
| Hold Up Time | 16msec (minimum) within 60% load |
| Input Current | 7A max |
| Input Frequency Range | 50 Hz - 60 Hz |
| Input Voltage | 230 Vac |
| Operating Temperature | 5? to +40? |
| Operating Humidity | 20% to 85%, non-condensing |
| Storage Temperature | -40? to +55? |
| Storage Humidity | 10% to 95%, non-condensing |
| Cooling System | 120mm Fan: 1800 R.P.M. ± 10% |
| Efficiency | 82-86% efficiency @ 20-100% load |
| MTBF | 100,000 hrs minimum |
| Safety Approval | CE/CB/TUV |
| PCI-E 6+2PIN | PCI-E 6+2pin x 2 |
