Name: Thermaltake Toughpower GX1 700W 80 PLUS Gold Power Supply
Brand: Thermaltake
SKU: PS-TPD-0700NNFAGA-1
Price: 114.40 AUD
Availability: OutOfStock

Thermaltake Toughpower GX1 700W 80 PLUS Gold Power Supply

Sku: PS-TPD-0700NNFAGA-1

Brand: Thermaltake

Category: Power Supplies

$114.40

Shipping Information

Availability: On Order

On Order - These items are sourced upon request and may take longer to deliver. We will confirm availability once your order is received, as some products may occasionally be discontinued or unavailable.

Shipping Calculator

Find

Discover the Thermaltake 700W Power Supply (PS-TPD-0700NNFAGU-1) with 80 PLUS Gold certification, active PFC, and a 12cm fluid dynamic bearing fan. Designed for ATX form factor with a peak output of 840W, ensuring high efficiency and reliability.

We Accept

Description

Manufacture: Thermaltake | Model: PS-TPD-0700NNFAGA-1

The SP-700AH2NCG is a high-performance power supply unit (PSU) engineered for reliability and efficiency, offering a stable 700W continuous output with a peak capacity of 840W. Designed to meet ATX 12V v2.4 and EPS v2.92 standards, this PSU is compatible with a wide range of modern components. With Active PFC (Power Factor Correction), it ensures stable power delivery, reducing power waste and improving energy efficiency. The PSU is equipped with a 12cm fluid dynamic bearing fan, which provides quiet and effective cooling while maintaining optimal temperatures during operation. Operating within an input voltage range of 100V-240V, it is suitable for use worldwide. The PSU features an 80 PLUS® Gold efficiency certification at 115Vac input, ensuring excellent energy-saving performance. It also includes a range of safety features such as CE, TUV, FCC, and more for maximum protection. With an MTBF of 100,000 hours, the SP-700AH2NCG is designed for long-term durability, making it a reliable choice for gaming PCs, workstations, and other demanding applications.

Key Features:

700W continuous output, 840W peak output
Meets ATX 12V v2.4 and EPS v2.92 standards for compatibility
80 PLUS® Gold certification for energy efficiency at 115Vac input
Active PFC (Power Factor Correction) for stable and efficient power delivery
12cm fluid dynamic bearing fan for quiet and effective cooling
Operating temperature range: 0°C to +40°C
Wide input voltage range of 100V-240V for global compatibility
MTBF of 100,000 hours for long-lasting reliability
Safety approvals including CE, TUV, FCC, BSMI, and more for quality assurance
PCI-E 6+2pin connectors x4 for supporting high-performance GPUs

P/N	PS-TPD-0700NNFAGU-1
Watts	700W
RGB Fan	No
Form Factor	ATX
Model	SP-700AH2NCG
Type	ATX 12V v2.4 and EPS v2.92
Max. Output Capacity	700W
Peak Output Capacity	840W
Color	Black
Dimension (W / H / D)	150mm(W) x 86mm(H) x 140mm(D)
PFC (Power Factor Correction)	Active PFC
Power Good Signal	100-500 msec
Hold Up Time	> 12msec at 80% of full load
Input Current	10A max.
Input Frequency Range	47Hz - 63Hz
Input Voltage	100V – 240V~
Operating Temperature	0°C to +40°C
Operating Humidity	20% to 90%, non-condensing
Storage Temperature	-20°C to +70°C
Storage Humidity	5% to 95%, non-condensing
Cooling System	12cm fluid dynamic bearing fan
Efficiency	Meet 80 PLUS® Gold at 115Vac input
MTBF	100,000 hrs minimum
Safety Approval	CE, cTUVus, TUV, FCC, BSMI, EAC, S-Mark
PCI-E 6+2pin	4
