Manufacture # Thermaltake | Model # CA-1X6-00F6WN-01
The CTE Form Factor Designed by Thermaltake, stands for Centralized Thermal Efficiency, and is focused around providing high level thermal performance to critical components. The design utilizes a 90-degree rotation of the motherboard providing more efficient airflow pathways.
Since the CPU location has been moved much closer to the front panel and the graphics card moved closer towards the rear panel, independent cold air induction is given for thermal dissipation of the CPU and graphics card respectively. This overall approach has allowed CTE to provide better and more efficient intake airflow through the placement of main components and cooling, as well as optimization to heat extraction from the system.
Features:
Overview:
Manufacturer Warranty: 03 Years Limited Warranty
| Color | White |
| SERIES | CTE |
| Case Type | Full Tower |
| Dimension (H X W X D) | 565.2 X 327 X 599.2 Mm (22.25 X 12.87 X 23.59 Inch) |
| Net Weight | 17.1 Kg / 37.7 Lbs. |
| Panel | 4mm Tempered Glass X 2 |
| Material | SPCC / ABS |
| Cooling System | Front(Intake): 140 X 140 X 25 Mm Ct140 Argb Fan (1500rpm, 30.5 Dba) X 1 Top(Exhaust): 140 X 140 X 25 Mm Ct140 Argb Fan (1500rpm, 30.5 Dba) X |
| Drive Bays | 7 X 3.5” Or 12 X 2.5” |
| Expansion Slots | 7 |
| Motherboards | 6.7” X 6.7” (Mini Itx), 9.6” X 9.6” (Micro Atx), 12” X 9.6” (Atx), 12” X 13” (E-atx) |
| I/O Port | Usb 3.2 (Gen 2) Type-c X 1, Usb 3.0 X 4, Hd Audio X 1 |
| Psu | Standard Ps2 Psu (Optional) |
| Fan Support | Front: 3 X 120mm, 2 X 120mm, 1 X 120mm 3 X 140mm, 2 X 140mm, 1 X 140mm 2 X 200mm, 1 X 200mm Top: 2 X 120mm, 1 X 120mm 2 X 140mm, 1 X 140mm Right (M/B Side): 3 X 120mm, 2 X 120mm, 1 X 120mm 3 X 140mm, 2 X 140mm, 1 X 140mm Rear: 3 X 120mm, 2 X 120mm, 1 X 120mm 3 X 140mm, 2 X 140mm, 1 X 140mm 2 X 200mm, 1 X 200mm Bottom: 3 X 120mm, 2 X 120mm, 1 X 120mm 3 X 140mm, 2 X 140mm, 1 X 140mm |
| Radiator Support | Front: 1 X 360mm, 1 X 240mm, 1 X 120mm 1 X 420mm(Aio Only), 1 X 280mm, 1 X 140mm Top: 1 X 240mm, 1 X 120mm 1 X 140mm Right (M/B Side): 1 X 360mm, 1 X 240mm, 1 X 120mm 1 X 420mm(Aio Only), 1 X 280mm, 1 X 140mm Rear: 1 X 360mm, 1 X 240mm, 1 X 120mm 1 X 420mm(Aio Only), 1 X 280mm, 1 X 140mm Bottom: 1 X 360mm, 1 X 240mm, 1 X 120mm 1 X 280mm, 1 X 140mm |
| Clearance | Cpu Cooler Max Height: 190mm Vga Max Length: 370mm (With Radiator) 420mm (Without Radiator) Psu Max Length: 220mm |
