Manufacture # Targus | Model # DOCK570AUZ
This sleek dock helps reduce clutter by providing the ease of a single connection for key peripherals like your mouse, keyboard, and more. Its rubberized, padded bottom protects against scratches, while the VESA bracket mounting provision allows for use of the Targus VESA Mount Bracket (ACX003GLZ sold separately) to hold your dock behind your display for even greater space savings. Your most advanced configurations become easy with compatibility across virtually any laptop and most standard peripherals including Thunderbolt 3, Display Port Alt-Mode, and USB 3.0, 3.1 and Type-C devices. Charging tips and a USB-C to USB-A adapter included to make this dock compatible with a variety of major laptop brands.
Features:
- Your workstation has never been more powerful with a high-performance quad-monitor dock.
- That supports full 4K (3840 x 2160 p60) resolution or DisplayPort (3840 x 2160 p60) on all four displays as well as viewing modes for two and three monitors.
- The eight available video out ports allow you to decide between HDMI or DP++ display options to ensure compatibility for your configuration.
- The Universal USB-C Quad 4K Docking Station with 100W Power Delivery is the first quad-docking solution designed to keep your devices running no matter how long your day is.
- A simple front-panel blue light lets you know when power is connected, and a switch allows you to turn your power on or off in a snap.
- Offering 100W USB power delivery on PD 2.0, you can power laptops and larger devices through your dock, further reducing your clutter and making it easy to keep going all day.
- Four USB 3.0 ports make it easy to customize workspaces with the latest keyboards, external drives other essential peripherals.
- Efficient charging is close at hand with one powered USB 3.0 port for keeping smartphone, tablet, or other devices powered up and ready to go.
Overview:
- Connection Technology: USB 3.2 G1
- Max Host Power: 100W
- Power Source: Wall
- HDMI: 4
- Weight: 815g
Manufacturer Warranty: 03 Years Limited Warranty
Supports DisplayPort and HDMI Monitors
Your workstation has never been more powerful with a high-performance quad-monitor dock that supports full 4K (3840 x 2160 p60) resolution or DisplayPort (3840 x 2160 p60) on all four displays as well as viewing modes for two and three monitors. The eight available video out ports allow you to decide between HDMI or DP++ display options to ensure compatibility for your configuration.
Powering Your Devices
The Universal USB-C Quad 4K Docking Station with 100W Power Delivery is the first quad-docking solution designed to keep your devices running no matter how long your day is. A simple front-panel blue light lets you know when power is connected, and a switch allows you to turn your power on or off in a snap. Offering 100W USB power delivery on PD 2.0, you can power laptops and larger devices through your dock, further reducing your clutter and making it easy to keep going all day.
Onboard USB 3.0 for Advanced Peripherals and Charging
Four USB 3.0 ports make it easy to customize workspaces with the latest keyboards, external drives, and other essential peripherals. Efficient charging is close at hand with one powered USB 3.0 port for keeping smartphone, tablet, or other devices powered up and ready to go.
What’s in the Box
- Dock
- User Guide (part #410-3878-001A)
- DC cable to power tip, 1M (part #511-0459-001C)
- Cable, Input US AC Cable Cord (part #511-0309-001C)
- Power Tips (part #PT-3A, #PT-3H, #PT-3H2, #PT-3I2, #PT-3P, #PT-3W, #PT-3X9)
- USB-C/M (screwed) to C/M (normal) Cable, 1M, 5A, 10Gbps (part #511-0515-001A)
- Adapter, AC to DC, output: 20V, 9A, 180W (part #800-0478-001A)
- USB-C/F to A/M Adapter (part #ACC1104GLX)
Enterprise Software Suite: A Targus Exclusive
Enhance security and improve user experience with the Targus Enterprise Software Suite for DOCK570USZ.
- Wi-Fi Auto Switch: auto enables/disables Wi-Fi functionality when the dock’s Ethernet connection is active, reducing unnecessary network traffic and enabling faster connection speeds.
- MAC Address Cloning: auto replaces the MAC address of the connected Targus Ethernet network adapter with any (Wired Ethernet, Wireless Ethernet, Bluetooth) MAC address of the local host, supporting device-based authentication methods.
- Ghost Device Removal: purges older, latent Targus docking station devices from the local registry preventing registry bloat.
