STARTECH Video Wall Mount - For 45 To 70 VIDWALLMNT

Availablity : In stock
Ships within 1 and 3 days
STARTECH VIDWALLMNT Video Wall Mount, Pop-Out Design, Micro-Adjustment, VESA Compatible, For up to 70" displays, Capacity up to 154.7 lb/display, Easily tilts, Anti-theft, Steel, BLACK   This professional video-wall mount features an innovative pop-out design that enables fast and easy display alignment and adjustment, within a multi-display video wall. ...

Estimated Shipping

Pay what you see.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa
  • Description
  • Specifications

Product Description

Manufacture # STARTECH | Model # VIDWALLMNT


Using multiple VIDWALLMNT wall mounts, you can create an impressive video wall, enabling you to align your displays in unison. It’s the ideal solution for public, business and commercial displays and includes a theft deterrence feature (padlock required).



  • Engineered with heavy-duty steel, the video-wall mount securely supports 45" to 70" displays, weighing up to 154 lb. (70 kg).
  • With its unique pop-out design, the video wall mount helps you align your displays with perfect precision.
  • Once installed, you simply press gently on the front of the display and the mount extends out from the wall for rear-screen access.
  • This pop-out feature makes it easy to adjust the position and angle of the display, or replace a display when required.
  • The video-wall mount features 6 points of micro-adjustment, with vertical, tilt and swivel adjustments, to provide exact display alignment and an optimum viewing angle.
  • You can tilt your display +3 / -5 degrees, adjust the swivel angle +1.2 / - 1.2 degrees, and rotate the display +3 / - 3 degrees.
  • The video-wall mount also features lateral shift brackets, making it easy to move the display to the left or right for ideal alignment in your video wall.
  • This video-wall mounting system is designed for easy set-up and maintenance.
  • The pop-out design also assists in installation and maintenance, plus a convenient kickstand allows you to tilt the display up to 12 degrees giving you extra room when adjusting cables or accessing ports.



  • Brand: STARTECH
  • Product Type: Video Wall Mount
  • Color: Black
  • Material: Steel
  • 6 points of micro-adjustment (vertical, tilt and swivel) for exact display alignment
  • Lateral shift brackets to adjust monitors, left or right, and swivel angle of +1.2 / -1.2 degrees for precise alignment


Manufacturer Warranty: 5 Years Limited Warranty


Technical Specifications

Product code VIDWALLMNT
# of Displays Supported 1
Mounting Options Wall-Mount
Minimum Profile from Wall 5.6 in [14.3 cm]
VESA Hole Pattern(s) 200x200 mm, 200x300 mm, 200x400 mm, 300x200 mm, 300x300 mm, 400x200 mm, 400x300 mm, 400x400 mm, 600X200 mm, 600x300 mm, 600x400 mm
Weight Capacity (Per Display) 154.7 lb [70 kg]
Minimum Display Size 45”
Maximum Display Size 70"
Video Wall Yes
Maximum Arm Extension 12.0 in [30.6 cm]
Display Tilt +3° / -5°
Anti-theft Yes
Color Black
Material Steel
Product Length 36.8 in [93.4 cm]
Product Width 12.0 in [30.6 cm]
Product Height 19.0 in [48.3 cm]
Weight of Product 29.8 lb [13.5 kg]
Note The video-wall mount is designed for precise display alignment. You can tilt your display +3° / -5°, adjust the swivel angle +1.2° / - 1.2°, and rotate the display +3° / - 3°.
Warranty 5 Years
