Startech M.2 Ngff Ssd To 2.5in Sata Iii Adapter SAT2M2NGFF25, 1 - Drive Connectors: M.2 (SATA, B-Key, NGFF), 1 - Host Connectors: SATA Data & Power Combo (7+15 pin), Interface: SATA, Number of Drives: 1, Compatible Drive Types: M.2 (SATA, B-Key, NGFF), Drive Installation: Fixed, Maximum Data Transfer Rate: 6 Gbps, Type and Rate: SATA III (6 Gbps), Hardware Raid Supported: No, Hot Swap Capability: No
The M.2 to SATA adapter features an enclosed housing that adds protection to your NGFF (Next Generation Form Factor) SSD. The added protection gives you the peace of mind to confidently use your M.2 drive in applications.
100% Guarantee Safe Checkout
Description
Manufacture # Startech | Model # SAT2M2NGFF25
The M.2 to SATA adapter features an enclosed housing that adds protection to your NGFF (Next Generation Form Factor) SSD. The added protection gives you the peace of mind to confidently use your M.2 drive in applications that require an added level of durability such as hot-swap drive bays, or external SATA docking stations.
Using an M.2 SSD in place of a platter drive better utilizes the full potential of your SATA III controller, by reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps -- an ideal solution for further increasing the performance of a HyperDuo array. For wide compatibility with all of the common M.2 solid state drives, the SAT2M2NGFF25 supports multiple drive heights including: 2242, 2260, 2280.
Features:
Overview:
Manufacturer Warranty: 02 Years Limited Warranty
Warranty | 2 Years |
1 - Drive Connectors | M.2 (SATA, B-Key, NGFF) |
1 - Host Connectors | SATA Data & Power Combo (7+15 pin) |
Operating Temperature | 0°C to 50°C (32°F to 122°F) |
Storage Temperature | -10°C to 85°C (14°F to 185°F) |
Humidity | 5% to 95% RH |
Interface | SATA |
Number of Drives | 1 |
Compatible Drive Types | M.2 (SATA, B-Key, NGFF) |
Drive Installation | Fixed |
Supported Drive Height(s) | 2230 / 2242 / 2260 / 2280 |
Package Height | 32 mm [1,3 in] |
Package Length | 13,1 cm [5,2 in] |
Shipping (Package) Weight | 116 g [4,1 oz] |
Package Width | 16,2 cm [6,4 in] |
Maximum Data Transfer Rate | 6 Gbps |
Type and Rate | SATA III (6 Gbps) |
Hardware Raid Supported | No |
Hot Swap Capability | No |
General Specifications | Not compatible with M.2 NVMe or AHCI PCI-Express SSDs |
Weight of Product | 54 g [1,9 oz] |
Color | Black |
Material | Aluminum and Plastic |
Product Length | 98 mm [3,9 in] |
Product Width | 68 mm [2,7 in] |
Product Height | 8 mm [0,3 in] |
OS Compatibility | OS independent; No software or drivers required |
1 - Included in Package | M.2 NGFF SSD to 2.5" SATA Adapter SSD mounting kit Housing mounting kit Mini screw driver Instruction manual |
