STARTECH 5 Port Industrial Ethernet Unmanaged Switch - Din IES5102

SKU : IES5102
Brand : StarTech
Availablity : In stock
Ships within 1 and 3 days
StarTech IES5102 5 Port Industrial Ethernet Switch, DIN Rail Mountable, Network up to 5 Ethernet devices through a rugged, energy-efficient, industrial 10/100Mbps Ethernet switch, DIN Rail Mountable, Cable 328 ft [100 m], Data Transfer Rate 200 Mbps (Full-Duplex), MTBF 1,179,133 Hours, Input Voltage 12 ~ 48 DC, Plastic, Black. The StarTech IES5102 is a compact 5-port industrial Ethernet switch is engineered to deliver fast, reliable network connectivity and durability in the most demanding industrial environments.
Ask a question about this product
$176.00

Estimated Shipping

Delivery when available

Pay what you see.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # StarTech | Model # IES5102



The StarTech IES5102 is a compact 5-port industrial Ethernet switch is engineered to deliver fast, reliable network connectivity and durability in the most demanding industrial environments. It provides top performance in a wider range of operating temperatures than conventional network switches, making it ideal for factories and warehouses. Designed with a rugged IP30-rated housing, the network switch delivers maximum performance even in harsh industrial conditions. Its wide-range terminal block input gives you the flexibility to power the switch as required, based on your own power input source, while its wide operating temperature range keeps your network running smoothly.



Features:

  • Network up to 5 Ethernet devices, even in industrial settings, with a robust IP30-rated switch
  • Wide-range 12-48V DC terminal block input
  • Easy installation with an integrated DIN rail bracket
  • IEEE 802.3az Energy-Efficient Ethernet
  • Supports 10BaseT/100BaseTX and Full-Duplex/Half-Duplex Auto-negotiation
  • Supports IEEE 802.3x flow control and back pressure
  • Store-and-forward switching mechanism
  • Wider range of operating temperatures, ideal for industrial environments.



Overview:

  • Full Duplex Support: Yes
  • Jumbo Frame Support: No
  • Maximum Cable Length: 328 ft [100 m]
  • Maximum Data Transfer Rate: 200 Mbps (Full-Duplex)
  • MTBF: 1,179,133 Hours



Manufacturer Warranty: 03 Years Limited Warranty

Technical Specifications

Product Type Ethernet Switch
Industry Standards IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX)
IEEE 802.3az (Energy-Efficient Ethernet)
IEEE 802.1P Quality of Service (QoS)
Interface RJ45 (10/100 Ethernet)
Ports 5
Regulatory Approvals EN61000-6-2
EN61000-6-4
EN61000-4-3 (Radiated RFI Standards)
EN61000-4-4 (Burst Standards)
EN61000-4-6 (Induced RFI Standards)
EN61000-4-8 (Magnetic Field Standards)
IEC60068-2-6 Fc (Vibration)
IEC60068-2-27 Ea (Shock)
Auto MDIX Yes
Buffer Size 56 KB
Compatible Networks 10/100 Mbps
Flow Control IEEE 802.3x Full-Duplex
Full Duplex Support Yes
Jumbo Frame Support No
Maximum Cable Length 328 ft [100 m]
Maximum Data Transfer Rate 200 Mbps (Full-Duplex)
MTBF 1,179,133 Hours
Switching Architecture Store-and-Forward
External Ports RJ-45 Female
Terminal Block (3 Wire)
OS Compatibility OS Independent; No additional drivers or software required
LED Indicators Power
Link/Activity
Activity (100 Mbps)
Input Voltage 12 ~ 48 DC
Power Consumption (In Watts) 2.12W Max
Power Source Terminal Block
Color Black
Enclosure Type Plastic
Product Height 4.3 in [110 mm]
Product Length 2.8 in [70 mm]
Product Weight 5.3 oz [150 g]
Product Width 1 in [25 mm]
