Startech 4-Port Gigabit Midspan PoE+ Injector Black

SKU : POEINJ4G
Brand : StarTech
Availablity : Online Only, In Stock
Ships within 1 and 3 days from our Seven Hills, NSW warehouse
Connector Type(s): 8 - RJ-45, Ports: 4, MTBF: 50,000 Hours, Power Source: AC Adapter Included, Input Voltage: 100 - 240 AC, Input Current: 2 A, 02 Years Limited Warranty, POEINJ4G.
Ask a question about this product
$260.00

Estimated Shipping

Pay what you see.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Startech | Model # POEINJ4G



It supplies up to 30 Watts output to each port, so you can easily power and access up to four high-power PoE-compliant devices such as IP cameras  using standard Ethernet cable.



Features:

  • Easily connect, power, and operate up to four Gigabit PoE-powered devices (PD)
  • Delivers full power to each port up to 30.8 watts (802.3at) or 15.4 watts (802.3af) to each connected device
  • Flexible setup, with a desktop-sized, or wall-mountable metal housing
  • Plug-and-play setup and operation
  • Automatically detects the powered device to provide the appropriate level of power output
  • Circuit protection prevents power interference between each port
  • Support for 10/100/1000 Mbps networks and devices, as well as Auto-Negotiation and auto-MDIX



Overview:

  • Connector Type(s): 8 - RJ-45
  • Ports: 4
  • MTBF: 50,000 Hours
  • Power Source: AC Adapter Included
  • Input Voltage: 100 - 240 AC
  • Input Current: 2 A



Manufacturer Warranty: 02 Years Limited Warranty

Technical Specifications

Connector Type(s) 8 - RJ-45
Hardware :-
Ports 4
Industry Standards IEEE 802.3af PoE, IEEE 802.3at PoE+
IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3ab (1000BASE-T)
Indicators :-
LED Indicators 1 - Power
4 - PoE In-Use
Performance :-
Maximum Data Transfer Rate 2 Gbps (Full-Duplex)
Maximum Cable Length 328.0 ft [100 m]
MTBF 50,000 Hours
General Specifications Power Output: 54V DC at 30.8W (PoE+)
Physical Characteristics :-
Weight of Product 7.1 oz [202.0 g]
Color Black
Material Steel
Product Length 3.7 in [9.4 cm]
Product Width 2.8 in [7.0 cm]
Product Height 1.0 in [2.6 cm]
Power :-
Power Source AC Adapter Included
Input Voltage 100 - 240 AC
Input Current 2 A
Output Voltage 54 DC
Output Current 2.4 A
Center Tip Polarity Positive
Plug Type M
Power Consumption (In Watts) 129.6
Included in Package 1 - 4 Port Gigabit PoE+ Injector
1 - Universal Power Adapter
4 - Power Cords (NA/JP, EU, UK, ANZ)
1 - DIN Rail Mount
1 - Instruction Manual
