StarTech 2-port 10Gbps USB C PCIe Card - USB 3.1 Gen 2 PCI Express Card

Description

Manufacture # StarTech | Model # PEXUSB312C3

Utilizing an ASMedia ASM3142 chipset, this card harnesses the speed of USB 3.2 Gen 2. With higher data throughput support, this USB 3.2 Gen 2 PCIe expansion card is a necessity for external drives and many other USB 3.2 Gen 2 peripherals and includes an optional SATA power connector for high power devices.


Features:

• High Performance- Add 2x USB-C SuperSpeed 10Gbps ports to your desktop PC with this USB 3.2 Gen 2x1 PCIe Card; Expansion card provides up to 5V 3A (15W) via the USB-C ports; Does not support DP-Alt mode for video over USB-C or USB Power Delivery
• Usb 3.2 Gen 2x1 Speeds- PCI Express card features the ASMedia ASM3142 host controller using x4 lanes of PCIe 3.0; Capable of speeds up to 10Gbps enabling fast access to high-performance devices like NVMe drives and SSDs
• Maximized Usb Performance- 2-port USB-C PCIe Card adapter supports USB Attached SCSI Protocol (UASP) optimizing USB performance; Installs in full/low-profile PCIe 3.0 x4 desktop / server slot (lower performance with PCI-e 2.0)
• Compatibility- Add-on card installs in full or low-profile (bracket included) PCIe 3.0 x4 slot (Backward compatible with PCIe 2.0); Windows/Linux/macOS with auto-install drivers Win 8 and up; Works with USB 3.2 Gen 2/3.0/2.0 devices


Overview:

• Connector Type(s): 1 - PCI Express x4
• Ports: 2
• Interface: USB 3.2 Gen 2
• Bus Type: PCI Express
• Maximum Data Transfer Rate: 10Gbps

Manufacturer Warranty: 02 Years Limited Warranty
