The Sony BRC-X1000 4K PTZ camera features a 1/2.5 type ExmorR CMOS sensor with 8.5M effective pixels. It supports up to 30x zoom, 1700 TV lines horizontal resolution, and multiple video resolutions including 4K. With advanced exposure control, fast pan/tilt speeds, NDI|HX capability, and multi-streaming, it’s perfect for high-quality live broadcasting.
We Accept
Manufacture: Sony | Model: SRG-A40W
The Sony 4K PTZ camera is a high-performance solution designed for professional broadcasting, live streaming, and remote production. Featuring a 1/2.5 type ExmorR CMOS sensor with approximately 8.5 million effective pixels, it delivers stunning 4K resolution with exceptional detail and clarity. The camera supports multiple signal formats, including 2160p, 1080p, and 720p, making it a versatile choice for various production needs. Equipped with a powerful 30x zoom in 4K mode (up to 80x in HD with Tele Convert Mode), it ensures precise and smooth zooming for capturing distant subjects. The advanced image stabilization, auto/manual focusing system, and intelligent exposure controls provide superior image quality in different lighting conditions. The PTZ mechanism offers an extensive pan range of ±170° and a tilt range from +90° to -20°, with customizable speed settings for smooth, silent operation. Supporting IP video streaming with H.264 and H.265 compression, the camera ensures efficient bandwidth management while maintaining high-quality output. With NDI|HX capability (license required), multiple streaming options, and support for a range of network protocols, this camera is designed for seamless integration into modern video production workflows.
| Image Sensor | 1/2.5 type ExmorR CMOS |
| Effective Pixels | Approx. 8.5M pixels |
| Signal System | 2160/29.97p, 25p, 23.98p 1080/59.94p, 50p, 29.97p, 25p, 23.98p 1080/59.94i, 50i 720/59.94p, 50p |
| 4K Capability | Yes |
| Minimum Illumination (50IRE) | 1.6 lux (1/30s 50IRE F2 high-sensitivity OFF) |
| Horizontal Resolution | 1700 TV lines (Center) (4K), 1000 TV lines or higher (Center) (FHD) |
| Gain | Auto/Manual (0 to +48 dB) |
| Shutter Speed | 1/1 to 1/10000 sec (59.94 Hz system) 1/1 to 1/10000 sec (23.98 Hz system) 1/1 to 1/10000 sec (50 Hz system) |
| Exposure Control | Auto/Manual/Priority AE (Shutter, Iris) |
| White Balance | Auto1/Auto2/One Push WB/Indoor/Outdoor/Manual |
| Zoom Capability | 30x (4K with CIZ), 40x (HD with CIZ), Max. 80x (HD with CIZ and Tele Convert Mode) |
| Focusing System | Auto/Manual |
| Horizontal Viewing Angle | Approx. 70.0° (Wide) |
| Focal Length | f = 4.4 mm (Wide) to 88.0 mm (Tele) |
| F-number | F2.0 to F3.8 |
| Minimum Object Distance | 80 mm (Wide) ~ 800 mm (Tele) |
| Pan/Tilt Angle | Pan: ±170° / Tilt: +90° to -20° |
| Pan/Tilt Speed (Max.) | Pan: 300°/s, Tilt: 126°/s |
| Pan/Tilt Speed (Normal) | Pan: 1.1° to 101°/s, Tilt: 1.1° to 91°/s |
| Pan/Tilt Speed (Slow Mode) | Pan: 0.5° to 60°/s, Tilt: 0.5° to 60°/s |
| Pan/Tilt Operation Noise | NC30 or less (*Sony measurement conditions) |
| Preset Position | 256 (CGI) / 100 (VISCA) |
| Picture Freeze Preset | Yes |
| PTZ Motion Sync | Yes |
| IP Video Resolution | 3840x2160, 1920x1080, 1280x720, 640x360 |
| Compression Format | H.264: High/Main/Baseline Profile, H.265: Main Profile |
| Maximum Frame Rate | H.264: 60fps, H.265: 60fps |
| Bitrate Compression Mode | CBR/VBR (selectable) |
| Range of Bitrate Setting | 512 Kbps ~ 50 Mbps |
| Multi Streaming Capability | 3 |
| Maximum Number of Clients | 5 |
| Supported Protocols | IPv4, IPv6, TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, VISCA over IP, SRT |
| NDI|HX Capability | Yes (Option - requires license) |
