Sony SRG-A40B 4K Ptz Camera 40x Optical With Ptz Auto Framing Black

Sku: SRG-A40B

Availability: Out of Stock

Brand: Sony

Category: IP Cameras

$6,696.80

The Sony BRC-X1000 4K PTZ camera offers 8.5M effective pixels with a 1/2.5 type ExmorR CMOS sensor, delivering excellent 4K video quality. It features up to 80x zoom, a variety of output interfaces, IP streaming, H.264/H.265 compression, and NDI|HX support. With advanced camera controls and various mounting options, it’s ideal for professional broadcast and video production.

-
+

100% Guarantee Safe Checkout

Thumbnail 3

Description

Manufacture: Sony | Model: SRG-A40B



With the advanced PTZ Auto Framing feature, the camera automatically tracks a person with smooth pan, tilt, and zoom movements, ensuring a comfortable viewing experience regardless of posture, movement, or attire. By automating most of the framing work, the camera allows operators to focus their time more efficiently.



Key Features:



  • High-speed pan and tilt for seamless tracking
  • Wide-angle zoom lens for expansive coverage
  • Powerful zoom with a wide field of view
  • PTZ Auto Framing for intelligent subject tracking
  • Preset camera positions for quick adjustments
  • Picture Freeze Preset to maintain framing consistency
  • Advanced autofocus (AF), auto exposure (AE), and auto white balance (AWB)
  • PTZ Motion Sync for smooth and natural movement transitions

Image Sensor 1/2.5 type ExmorR CMOS
Number of Effective Pixels Approx. 8.5M pixels
Signal System 2160/29.97p, 25p, 23.98p, 1080/59.94p, 50p, 29.97p, 25p, 23.98p, 1080/59.94i, 50i, 720/59.94p, 50p
4K Capability Yes
Minimum Illumination (50IRE) 1.6 lux (1/30s 50IRE F2 high-sensitivity OFF)
Horizontal Resolution 1700 TV lines (Center) (4K), 1000 TV lines or higher (Center) (FHD)
Gain Auto/Manual (0 to +48 dB)
High Sensitivity On Yes
Shutter Speed 1/1 to 1/10000 sec (59.94 Hz system), 1/1 to 1/10000 sec (23.98 Hz system), 1/1 to 1/10000 sec (50Hz system)
Exposure Control Auto/Manual/Priority AE (Shutter, Iris)
White Balance Auto1/Auto2/One Push, WB/Indoor/Outdoor/Manual
Zoom Capability 20x (Optical zoom), 30x (4K with CIZ*1), 40x (HD with CIZ), Max. 80x (HD with CIZ and Tele Convert Mode)
Focusing System Auto/Manual
Horizontal Viewing Angle Approx. 70.0 degree (Wide)
Focal Length f=4.4mm (Wide) to 88.0mm (Tele)
F-number F2.0 to F3.8
Minimum Object Distance 80 mm (Wide)~ 800 mm (Tele)
Pan/Tilt Angle Pan: ±170°, Tilt: +90°/-20°
Pan/Tilt Speed (Max.) Pan: 300 degrees/sec, Tilt: 126 degrees/sec
Pan/Tilt Speed Pan: 1.1° to 101°/s, Tilt: 1.1° to 91°/s
Pan/Tilt Slow Mode Yes
Pan/Tilt Operation Noise NC30 or less
Preset Position 256 (CGI), 100 (VISCA)
Picture Freeze Preset Yes
PTZ Motion Sync Yes
Network IP Video Resolution: 3840x2160, 1920x1080, 1280x720, 640x360
Compression Format H.264: High/Main/Baseline Profile, H.265: Main Profile
Maximum Frame Rate H.264: 60fps, H.265: 60fps
Bitrate Compression Mode CBR/VBR (selectable)
Range of Bitrate Setting 512 kbps~50 Mbps
Multi Streaming Capability 3
Maximum Number of Clients 5
Protocols IPv4, IPv6, TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, VISCA over IP, SRT
NDI|HX Capability Yes (Option, need to attach a license)
Camera Features Auto ICR, Day/Night, Visibility Enhancer, Image Stabilizer, Image Flip, Picture Setting File, Flicker Cancel, Hide OSD Menu, Standby Mode, Remote Standby, PTZ Auto Framing
Web UI Version Up Yes
Languages Japanese, English, French, Spanish, German, Italian, Chinese, Traditional Chinese, Korean, Portuguese, Russian, Polish, Hindi, Turkish
OS and Browser Windows 11/10 (64-bit) with Chrome/Edge, macOS (v. 10.14.x +) with Chrome
Audio Channel 2ch
Audio Codec AAC LC 128kbps/ST (IP), AAC LC 256kbps/ST (IP)
Embedded Audio in Baseband Video Yes (3G-SDI, HDMI)
Embedded Audio in IP Streaming Yes
Interface 4K Video Output: HDMI x1, IP (streaming) x1
HD Video Output: 3G-SDI x1, HDMI x1, IP (streaming) x1
SD Video Output: IP (streaming) x1
Camera Control Interface VISCA RS-422 RJ45 (In/Out), VISCA over IP RJ45
IR Remote Control Yes
Microphone Input Stereo Mini-phone (φ3.5mm) x1 (Mic/Line Selectable)
Sync. System INT
Tally Front x 1 (Red/Green for PTZ Auto Framing)
Power Connector Type IEC60130-10 (JEITA standard RC-5320A) Type5
Power Requirements DC 19.5V, PoE++ (IEEE802.3bt type4 class8)
Power Consumption DC19.5V: 80W, PoE++: 71.3W
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature -20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (W x H x D) 156.7 x 184.0 x 200.0 mm (6 1/4 x 7 1/4 x 7 7/8 inch)
Mass Approx. 2.0 kg (4 lb 6.5 oz)
Body Color White/Black
Size of Screw Hole for Tripod 1/4-20UNC x1
Mountable Angle < ±15°
Ceiling Mount Yes
