| Image Sensor |
1/2.5 type ExmorR CMOS |
| Image Sensor (Number of Effective Pixels) |
Approx. 8.5M pixels |
| Signal System |
2160/29.97p, 25p, 23.98p, 1080/59.94p, 50p, 29.97p, 25p, 23.98p, 1080/59.94i, 50i, 720/59.94p, 50p |
| 4K Capability |
Yes |
| Minimum Illumination (50IRE) |
1.6 lux (1/30s 50IRE F2 high-sensitivity OFF) |
| Horizontal Resolution |
1700 TV lines (Center) (4K), 1000 TV lines or higher (Center) (FHD) |
| Gain |
Auto/Manual (0 to +48 dB), High Sensitivity On |
| Shutter Speed |
1/1 to 1/10000 sec (59.94 Hz, 23.98 Hz, 50 Hz system) |
| Exposure Control |
Auto/Manual/Priority AE (Shutter, Iris) |
| White Balance |
Auto1/Auto2/One Push, WB/Indoor/Outdoor/Manual |
| Zoom Capability |
20x (Optical zoom), 30x (4K with CIZ), 40x (HD with CIZ), Max. 80x (HD with CIZ and Tele Convert Mode) |
| Focusing System |
Auto/Manual |
| Horizontal Viewing Angle |
Approx. 70.0 degree (Wide) |
| Focal Length |
f=4.4 mm (Wide) to 88.0 mm (Tele) |
| F-number |
F2.0 to F3.8 |
| Minimum Object Distance |
80 mm (Wide) – 800 mm (Tele) |
| Pan/Tilt Angle |
Pan: ±170°, Tilt: +90°/-20° |
| Pan/Tilt Speed (Max.) |
Pan: 300 degrees/sec, Tilt: 126 degrees/sec |
| Pan/Tilt Speed |
Pan: 1.1° to 101°/s, Tilt: 1.1° to 91°/s |
| Pan/Tilt Speed (Slow) |
Pan: 0.5° to 60°/s, Tilt: 0.5° to 60°/s |
| Pan/Tilt Slow Mode |
Yes |
| Pan/Tilt Operation Noise |
NC30 or less |
| Preset Position |
256 (CGI), 100 (VISCA) |
| Picture Freeze Preset |
Yes |
| PTZ Motion Sync |
Yes |
| IP Video Resolution |
3840 x 2160, 1920 x 1080, 1280 x 720, 640 x 360 |
| Compression Format |
H.264: High/Main/Baseline Profile, H.265: Main Profile |
| Maximum Frame Rate |
H.264: 60fps, H.265: 60fps |
| Bitrate Compression Mode |
CBR/VBR (selectable) |
| Range of Bitrate Setting |
512 kbps~50 Mbps |
| Multi-Streaming Capability |
3 |
| Maximum Number of Clients |
5 |
| Protocols |
IPv4, IPv6, TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, VISCA over IP, SRT |
| NDI|HX Capability |
Yes (Option, need to attach a license) |
| Camera Features |
Auto ICR, Day/Night, Visibility Enhancer, Image Stabilizer, Image Flip, Picture Setting File, Flicker Cancel, Hide OSD Menu, Standby Mode, Remote Standby, PTZ Auto Framing |
| Web UI Version Up |
Yes |
| Languages |
Japanese, English, French, Spanish, German, Italian, Chinese, Traditional Chinese, Korean, Portuguese, Russian, Polish, Hindi, Turkish |
| Audio Channel |
2 ch |
| Audio Codec |
AAC LC 128 kbps/ST (IP), AAC LC 256 kbps/ST (IP) |
| Embedded Audio in Baseband Video |
Yes (3G-SDI, HDMI) |
| Embedded Audio in IP Streaming |
Yes |
| 4K Video Output |
HDMI x1, IP (streaming) x1 |
| HD Video Output |
3G-SDI x1, HDMI x1, IP (streaming) x1 |
| SD Video Output |
IP (streaming) x1 |
| Remote Video Format Switching |
Yes |
| HDMI Color Space |
YCbCr, 4:2:2 8bit, RGB, 4:4:4 8bit |
| Camera Control Interface |
VISCA RS-422 RJ45 (In/Out), VISCA over IP RJ45 |
| IR Remote Control |
Yes |
| Microphone Input |
Stereo Mini-phone (φ3.5 mm) x1, (Mic/Line Selectable) |
| Sync. System |
INT |
| Tally |
Front x 1, Red/Green (for PTZ Auto Framing) |
| Power Connector Type |
IEC60130-10 (JEITA standard RC-5320A) Type5 |
| Power Requirements |
DC 19.5 V, PoE++ (IEEE802.3bt type4 class8) |
| Power Consumption |
DC 19.5 V: 80W, PoE++: 71.3W |
| Operating Temperature |
0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature |
-20 °C to +60 °C (-4 °F to +140 °F) |
| Dimensions (W x H x D) |
156.7 x 184.0 x 200.0 mm (6 1/4 x 7 1/4 x 7 7/8 in) |
| Mass |
Approx. 2.0 kg (Approx. 4 lb 6.5 oz) |
| Body Color |
White/Black |
| Size of Screw Hole for Tripod |
1/4-20UNC x1 |
| Mountable Angle |
< ±15° |
| Ceiling Mount |
Yes |
| Accessories |
AC power adaptor (1), IR Remote Commander Unit (1), Ceiling bracket (2), Wire rope (1), Screw M3 x 8 (9), Screw M2.6 x 6 BLACK (1), HDMI cable fixing plate (1), Safety regulation (1), Download site information (1), Warranty (1) |
