Sony SRG-A40 4K PTZ Camera with AI and 30x/40x Clear Image Zoom Black

SKU : SRGA40B
Brand : Sony
Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse
Image Sensor: 1/2.5"-Type CMOS, Horizontal Resolution (TV Lines): 1700 TV Lines, Shutter Type: Electronic Rolling Shutter, Shutter Speed: 1/10000 to 1 Second, Gain: 0 to 48 dB, Minimum Illumination: 1.6 Lux at 1/30 Shutter Speed, Focal Length: 4.4 to 88mm, Optical Zoom Ratio: 20x, Warranty: 02 Years, SRGA40B.
Ask a question about this product
$6,050.00

Estimated Shipping

Pay what you see.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Sony | Model # SRGA40B



A 1/2.5-type Exmor R CMOS sensor powers the Sony SRG-A40 4K PTZ Camera in Black, providing outstanding image quality even in low light. In addition, the SRG-A40 has sophisticated AI technology that can recognize and follow objects and people inside the camera's field of vision. Because of this, it's perfect for uses like live streaming events, video conferencing, and lecture capture.


Additionally, the camera has an optical zoom lens with a 30x magnification that is expandable to 40x using Clear Image Zoom, enabling close-ups of far-off scenes without sacrificing image quality. The Sony SRG-A40 has additional capabilities such an integrated web interface for remote control and monitoring, as well as several video outputs including 3G-SDI, HDMI, and IP streaming. The camera is compatible with a variety of control systems and can also be operated via RS-232 or RS-422.



Features:

  • Powerful AI-powered video analytics enable the SRG-A40 PTZ camera to automatically detect and track the position of a presenter within the frame.
  • As the presenter moves, the camera’s pan/tilt/zoom mechanism frames them naturally.
  • Eliminates the need for a human camera operator to manually follow their movements.
  • Automatically detects and tracks your subject even when others are present in the same frame.
  • Choose from three shooting modes to best suit your presentation.
  • Modes include Full Body, Waist, and Close Up.
  • Each mode offers centre, left, and right angles.



Overview:

  • Image Sensor: 1/2.5"-Type CMOS
  • Horizontal Resolution (TV Lines): 1700 TV Lines
  • Shutter Type: Electronic Rolling Shutter
  • Shutter Speed: 1/10000 to 1 Second
  • Gain: 0 to 48 dB
  • Minimum Illumination: 1.6 Lux at 1/30 Shutter Speed
  • Focal Length: 4.4 to 88mm
  • Optical Zoom Ratio: 20x



Manufacturer Warranty: 02 Years Limited Warranty

Technical Specifications

Imaging :-
Image Sensor 1/2.5"-Type CMOS
Horizontal Resolution (TV Lines) 1700 TV Lines
Sensor Resolution Effective: 8.5 Megapixel
IR Cut Filter Yes
Built-In ND Filter None
Focus Control Autofocus
Manual Focus
Exposure Control :-
Shutter Type Electronic Rolling Shutter
Shutter Speed 1/10000 to 1 Second
Gain 0 to 48 dB
Minimum Illumination 1.6 Lux at 1/30 Shutter Speed
Flip / Mirror Support Image Flip
White Balance Presets: Auto, Indoors, Manual, One Push, Outdoors
Lens :-
Focal Length 4.4 to 88mm
Optical Zoom Ratio 20x
Max Digital Zoom 30x ( in DCI 4K)
40x ( in 1080p)
Field of View Horizontal: 70°
Maximum Aperture f/2 to 3.8
Minimum Focus Distance Wide: 3.1" / 8.0 cm
Telephoto: 31.5" / 80.0 cm
Video Capture :-
External Recording Modes 4:4:4/4:2:2 8-Bit via HDMI
3840 x 2160 at 23.98/25/29.97 fps
1920 x 1080p at 23.98/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
1280 x 720 at 50/59.94 fps

SDI/BNC / RJ45
3840 x 2160 at 23.98/25/29.97 fps
1920 x 1080p at 23.98/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
1280 x 720 at 50/59.94 fps
Audio Recording 2-Channel AAC LC Audio
Broadcast Output NTSC/PAL
IP Streaming H.264, H.265, RTP, RTSP, SRT, TCP, UDP
3840 x 2160 at 60p (0.5 to 50.00 Mb/s)
1920 x 1080 at 60p (0.5 to 50.00 Mb/s)
1280 x 720 at 60p (0.5 to 50.00 Mb/s)
640 x 360 at 60p (0.5 to 50.00 Mb/s)
IP Multi-Stream Support Simultaneous
H.264, H.265, RTP, RTSP, TCP, UDP: UHD 4K, 1080p, 720p, 360p at 60p
Control :-
Presets 256 via CGI
100 via VISCA
Move Speed Pan: 0.5 to 300°/sec
Tilt: 0.5 to 126°/sec
Movement Range Pan: 340° (-170 to 170°)
Tilt: 110° (-20 to 90°)
Tally Light Yes
Supported Control Protocols IR
RS-422
VISCA
Interface :-
Video I/O 1 x HDMI Output
1 x BNC (3G-SDI) Output
1 x RJ45 Output
Audio I/O 1 x 1/8" / 3.5 mm TRS Stereo Microphone Input
Other I/O 1 x RJ45 (RS-422, VISCA) Control Input
1 x RJ45 (RS-422, VISCA) Control Output
1 x RJ45 (LAN) (Shared with Video Output)
Power :-
PoE Support PoE++ 802.3bt
Power I/O 1 x Barrel (19.5VDC) Input
Power Consumption Device: 80 W
PoE: 71.3 W
Environmental :-
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 140°F / -20 to 60°C
General :-
Mounting 1 x 1/4"-20 Female for Tripod
Color Black
OS Compatibility Windows 10 to 11 (64-Bit Only)
macOS 11 to 12
*As of April, 2023: Check with manufacturer for the most up-to-date compatibility
Sound Level NC30 (at Full Speed)
Dimensions (W x H x D) 6.2 x 7.2 x 7.9" / 156.7 x 184 x 200 mm
Weight 4.4 lb / 2.0 kg
