Sony SRG-A12B 4k Ptz Camera 12x Optical With Ptz Auto Framing Black

Sku: SRG-A12B

Availability: Out of Stock

Brand: Sony

Category: IP Cameras

$5,624.30

Shipping Calculator

This 4K PTZ camera features a 1/2.5-type Exmor R CMOS sensor with approximately 8.5 million effective pixels, delivering high-resolution video up to 2160p. Equipped with 12x optical zoom (24x in HD mode), auto/manual focus, and wide pan-tilt coverage, it ensures exceptional image clarity and flexibility. It supports multiple video outputs, including HDMI, 3G-SDI, and IP streaming, with H.264/H.265 compression. Ideal for professional broadcasting, live events, and remote monitoring, it offers PoE++ support, VISCA over IP control, and advanced streaming capabilities.

-
+

100% Guarantee Safe Checkout

Thumbnail 3

Description

Manufacture: Sony | Model: SRG-A12B



The camera is equipped with a 1/2.5-type ExmorR CMOS image sensor, offering approximately 8.5 million effective pixels for high-resolution imaging. It supports 4K video recording with multiple signal formats, including 2160p, 1080p, and 720p at various frame rates. With a 12x optical zoom and up to 24x zoom in HD mode, the camera provides flexible shooting capabilities. The auto/manual focusing system, along with an expansive horizontal viewing angle of approximately 70 degrees, ensures precise image capture. Its pan and tilt functionality allow for a broad range of movement, with pan angles of ±170° and tilt angles of +90°/-20°. The camera supports advanced IP streaming with H.264 and H.265 compression, enabling resolutions up to 3840x2160 and multi-streaming for up to five clients. Additional features include image stabilization, auto day/night mode, PTZ auto framing, and an intuitive Web UI for easy remote control. It offers multiple connectivity options such as HDMI, 3G-SDI, VISCA RS-422, and IP-based control, ensuring seamless integration with professional workflows. The camera operates at a power consumption of 80W (DC 19.5V) and supports PoE++. Compact and lightweight, it measures 156.7 x 184.0 x 200.0 mm and weighs approximately 2.0 kg, making it suitable for a variety of mounting options, including ceiling installation.



Key Features:



  • 1/2.5-type ExmorR CMOS sensor with 8.5M effective pixels
  • 4K video capability with multiple resolution and frame rate options
  • 12x optical zoom, up to 24x with TeleConvert Mode in HD
  • Wide horizontal viewing angle of approximately 70°
  • Pan/Tilt operation with ±170° pan and +90°/-20° tilt
  • Advanced IP streaming with H.264 and H.265 compression
  • Multi-client support for up to five simultaneous connections
  • Auto day/night mode with image stabilization and visibility enhancer
  • HDMI, 3G-SDI, VISCA RS-422, and IP-based control connectivity
  • Web UI support with multilingual interface
  • Compact and lightweight design, mountable at various angles
  • Power-efficient operation with DC 19.5V or PoE++

Image Sensor 1/2.5-type ExmorR CMOS
Effective Pixels Approx. 8.5M pixels
Signal System 2160/29.97p, 25p, 23.98p
1080/59.94p, 50p, 29.97p, 25p, 23.98p
1080/59.94i, 50i
720/59.94p, 50p
4K Capability Yes
Minimum Illumination 1.6 lux (1/30s 50IRE F2 high-sensitivity OFF)
Horizontal Resolution 1700 TV lines (Center) (4K)
1000 TV lines or higher (Center) (FHD)
Gain Auto/Manual (0 to +48 dB)
Shutter Speed 1/1 to 1/10000 sec (59.94 Hz system)
1/1 to 1/10000 sec (23.98 Hz system)
1/1 to 1/10000 sec (50 Hz system)
Exposure Control Auto/Manual/Priority AE (Shutter, Iris)
White Balance Auto1/Auto2/One Push/WB Indoor/Outdoor/Manual
Zoom 12x Optical, up to 24x (HD with TeleConvert Mode)
Focusing System Auto/Manual
Horizontal Viewing Angle Approx. 70° (Wide)
Focal Length f=4.4mm (Wide) to 88.0mm (Tele)
Pan/Tilt Angle Pan: ±170°, Tilt: +90°/-20°
Pan/Tilt Speed Max Pan: 300°/s, Max Tilt: 126°/s
Normal Pan: 1.1° to 101°/s, Normal Tilt: 1.1° to 91°/s
Slow Mode Pan: 0.5° to 60°/s, Slow Mode Tilt: 0.5° to 60°/s
IP Video Resolution 3840x2160, 1920x1080, 1280x720, 640x360
Compression Format H.264 (High/Main/Baseline Profile), H.265 (Main Profile)
Maximum Frame Rate 60 fps (H.264, H.265)
Bitrate Compression Mode CBR/VBR (selectable)
Maximum Clients 5
Network Protocols IPv4, IPv6, TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, VISCA over IP, SRT
Audio 2 Channels
AAC LC 128kbps/ST (IP), AAC LC 256kbps/ST (IP)
Embedded Audio in Baseband Video (3G-SDI, HDMI)
Video Output 4K: HDMI, IP Streaming
HD: 3G-SDI, HDMI, IP Streaming
SD: IP Streaming
Power Requirements DC 19.5V, PoE++ (IEEE802.3bt type4 class8)
Power Consumption DC 19.5V: 80W, PoE++: 71.3W
Dimensions (W x H x D) 156.7 x 184.0 x 200.0 mm
Weight Approx. 2.0 kg (4 lb 6.5 oz)
Body Color White/Black
Mounting Ceiling Mount Supported
