Shuttle NC40U Intel Core i7-1255U Chip processor

SKU : NC40U
Brand : Shuttle
Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse
Processor: Intel 12th Gen Celeron 7305 15W CPU, Audio: C-Media CM6542, Storage Interface: Support SATA 6.0Gb/s bandwidth, Drive Bays: 2.5" 15mm SATA HDD / SSD, Warranty: 03 Years, NC40U.
Ask a question about this product
$524.00

Estimated Shipping

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Shuttle | Model # NC40U



Shuttle’s latest XPC nano NC40U series houses the performance hybrid architecture of Intel 12th Gen Alder Lake-U platform, capable of multitasking and parallelism, and with Intel Iris Xe graphics for powering AI workloads, including taking the graphics and multimedia processing to a new level. Despite its 0.85L palm size design, it can accommodate one 2.5" hard disk (up to 15mm) and enable additional M.2 SSDs or NVMe SSD installation for flexible storage capacity. Combined with rich I/Os as USB 3.2 Gen2, USB 3.2 Gen1, and Intel Gigabit Lan, supporting triple display by the HDMI, DisplayPort, and Type-C that increase the functionality to adapt to various business computing to suit digital signage, Kiosk, edge computing, and video conference.



Features:

  • The NC40U series provides an HDMI 2.0b, a DisplayPort 1.4a, and a Type-C to reach three independent displays, supporting resolutions up to 4096 x 2160 / 3840 x 2160 @60Hz.
  • With two native M.2 2280 Type M slots and one M.2 2230 Type E slot, the NC40U series offers considerably faster storage and expandability of M.2 SSDs, or NVMe SSDs and Wi-Fi modules.
  • Despite its tiny body, the NC40U series allows easy installation of up to 1x 15mm (7/9.5/12.5/15mm) 2.5" HDD/SSD to provide a more flexible storage capacity without volume restriction.
  • NC40U series features flexible connectivity options for two USB 3.2 Gen2 and five 3.2 Gen1 (Including one Type-C) and an Intel  1GbE Lan that support Wake on LAN functions.



Overview:

  • Processor: Intel 12th Gen Celeron 7305 15W CPU
  • Audio: C-Media CM6542
  • Storage Interface: Support SATA 6.0Gb/s bandwidth
  • Drive Bays: 2.5" 15mm SATA HDD / SSD



Manufacturer Warranty: 03 Years Limited Warranty

Technical Specifications

Form Factor Shuttle 0.85L Form Factor
Processor Intel 12th Gen Celeron 7305 15W CPU
i3-1215U, i5-1235U, i7-1255U (optional)
Memory 2 x 260 pin DDR4 SODIMM slots, 32GB per DIMM (Max 64GB)
Dual Channel DDR4 ,up to 3200Mhz
Video Output Intel Iris Xe Graphics
Audio C-Media CM6542
Ethernet Built in Intel I219 support 10/100/1000Mbs
Storage Interface Support SATA 6.0Gb/s bandwidth
Front Panel (1)Power button
(1)Power LED
(1)HDD LED
(2)USB 3.2 Gen 1 Type A
(1)USB 3.2 Gen 1 Type C (w/DP)
Back Panel (1)HDMI
(1)DisplayPort
(2)USB 3.2 gen1
(2)USB 3.2 gen2
(1)RJ45
(1)DC-in Jack
(1)Kensington Lock
Drive Bays (1)2.5" 15mm SATA HDD / SSD
Dimensions 142(L) x 142(W) x 42(H) mm
Power 65 Watts (19V/3.42A)
Accessories Quickguide
DVD driver
VESA mount
Foot Stand
Adapter and power cord
screw pack
Expansion Slot (1)M.2 2230 E key
(1)M.2 2280 M key(w/PCIe Gen3 x 4, SATA 6 Gb/s)
(1)M.2 2280 M key(w/PCIe Gen4 x 4)
Os Support Windows 11 Linux
Operating Temperature 0°C~50°C
