This power supply features a Gold 80PLUS® certification, fully modular cables, and a 135mm fan with fluid dynamic bearing, ensuring optimal efficiency, performance, and reliability. Rated for 850W continuous power with advanced protection features, it is designed to operate under demanding conditions and provides a 10-year warranty.
We Accept
Manufacture: Seasonic | Model: PSUSEAFOCUSGX850V4
The 850W ATX/EPS power supply is a high-efficiency unit designed for demanding computing needs, including gaming PCs and professional workstations. With an 80 PLUS Gold certification, it delivers up to 90% efficiency at typical loads, reducing energy waste and enhancing system stability. Featuring a 135mm Fluid Dynamic Bearing (FDB) fan with Digital Hybrid Fan Control, it provides effective cooling while maintaining low noise levels. Its fully modular design, paired with individually braided black cables, ensures a clean and organized build. Engineered for reliability, the PSU boasts a fan life expectancy of 50,000 hours at 40°C and an MTBF of 100,000 hours at 25°C (excluding the fan). Supporting full-range AC input (100-240V) and delivering a strong +12V rail output of 70A, it is capable of powering high-end components. The unit includes comprehensive protection features such as OCP, OPP, OTP, OVP, SCP, and UVP to safeguard against electrical issues. Certified for global safety and environmental standards, including CE, FCC, RoHS, and Energy Star, it guarantees long-term performance. Backed by a 10-year warranty, this power supply is a reliable and future-proof investment for high-performance systems.
| 80PLUS® Certification | Gold |
| Cybenetics Efficiency Level | TBA |
| Cybenetics Noise Level | TBA |
| Form Factor | ATX/EPS |
| Fan Information | Fan Size: 135 mm |
| Fan Control: Digital Hybrid Fan Control | |
| Fan Bearing: Fluid Dynamic Bearing | |
| Life Expectancy: 50,000 hours at 40°C, 15% - 65% RH | |
| Cable Information | Modularity: Fully Modular |
| Cable Type: Individual Black Cables with Braided Pattern | |
| Electrical Features | Operating Temperature: 0 - 50°C |
| MTBF @ 25 °C, excl. fan: 100,000 hours | |
| AC Input: Full Range | |
| Protection | OCP, OPP, OTP, OVP, SCP, UVP |
| Safety and Environmental | Safety and EMC: CB, CCC, CE, cTUVus, EAC, TUV, BSMI, FCC |
| Environmental Compliance: Energy Star, ErP Lot 6, REACH, RoHS, WEEE | |
| Warranty | 10 Years |
| Power Output | AC Input: Voltage: 100 V - 240 V, Current: 11 - 5.5 A, Frequency: 50 Hz - 60 Hz |
| DC Output: +3.3V @ 20A, +5V @ 20A, +12V @ 70A, -12V @ 0.3A, +5VSB @ 3A | |
| Maximum Power: 100W (3.3V & 5V), 840W (+12V), 3.6W (-12V), 15W (+5VSB) | |
| Total Continuous Power: 850W |
