Qnap SFP+ 10GBE Twinaxial Direct At Tach Cable NAS Accessories CAB-DAC15M-SFPP

Qnap SFP+ 10GBE Twinaxial Direct At Tach Cable NAS Accessories (CAB-DAC15M-SFPP)

Sku: CAB-DAC15M-SFPP

Brand: QNAP

Category: NAS Accessories

$96.80

Shipping Information

Availability: On Order

On Order - These items are sourced upon request and may take longer to deliver. We will confirm availability once your order is received, as some products may occasionally be discontinued or unavailable.

Shipping Calculator

Find

Qnap CAB-DAC15M-SFPP SFP+ 10GBE Twinaxial Direct At Tach Cable, Form Factor: SFP+ DAC Cable, Data Rate: 10.5Gb/s, Passive or actively equalized: Passive, Supply Voltage: 3.3V, Cable Length: 1.5 m, Cable impedance: 100 ?, Cable Type: Twinax, Wire Gauge: 30AWG, Minimum cable bend radius: 25 mm, Cable Jacket Type: PVC, Connector: SFP+. Connect network-attached storage or other compatible devices to 10 Gb/s networks with the SFP+ 10GbE Twinaxial Direct Attach Cable from QNAP.

We Accept

Description

Manufacture # Qnap | Model # CAB-DAC15M-SFPP

This QNAP CAB-DAC15M-SFPP compatible DAC provides high performance and cost-effective SFP+ direct attach copper cable with a length of 1.5 meters (5 ft). It supports the bandwidth transmission requirements as defined by 10 Gigabit-Ethernet (10GBase-CU), 8G Fiber Channel (FC) and 10G Fiber Channel over Ethernet (FCoE). Every cable is individually programmed and tested to work with QNAP 10G switches, routers, network adapters, and network storage systems. It offers a low-cost alternative to genuine QNAP CAB-DAC15M-SFPP high-speed cable assemblies.

Features:

Functionally identical to QNAP CAB-DAC15M-SFPP
Support for multi-gigabit data rates up to 10.5Gbps
I/O Connector designed for high-speed differential signal applications
Improved Pluggable Form Factor (IPF) compliant with enhanced EMI/EMC performance
Single 3.3V power supply
Operating temperature range: 0 to 70°C
RoHS Compliant and Lead-Free

Overview:

2 x SFP+ Connectors
Cable Length: 1.5 m
Form Factor: SFP+ DAC Cable
Cable Type: Twinax

Manufacturer Warranty: 01 Years Limited Warranty

Form Factor	SFP+ DAC Cable
Data Rate	10.5Gb/s
Passive or actively equalized	Passive
Supply Voltage	3.3V
Cable Length	1.5 m
Cable impedance	100 Ω
Cable Type	Twinax
Wire Gauge	30AWG
Minimum cable bend radius	25 mm
Cable Jacket Type	PVC
Connector	SFP+
Digital Diagnostic Monitoring	N/A
Environment	Operating: 0°C to 70°C Storage: -40°C to 85°C
Weight	0.18 kg
Application	Storage Area Networks( SAN) Network Attached Storage Switched fabric I/O High density connections between networking equipment Data center cabling infrastructure
Compliance	SFF-8472,SFF-8431 IEC/EN 61000-4-2 MIL-STD-883E, RoHS
