Sku: 2200-49735-025
Brand: Poly
Category: Headset Systems
Shipping Information
Availability: On Order
On Order - These items are sourced upon request and may take longer to deliver. We will confirm availability once your order is received, as some products may occasionally be discontinued or unavailable.
Shipping Calculator
Find
User Interface: 5" color LCD, Aspect Ratio: 9:16, Network and Provisioning: SIP protocol support, Warranty: 01 Year, 2200-49735-025.
100% Guarantee Safe Checkout
Description
Manufacture # Poly | Model # 2200-49735-025
The Poly CCX 505 Business Media Phone has workers feeling confident they’ll sound professional on every call. No word or inflection is missed, thanks to legendary audio quality, Poly HD Voice, and Poly Acoustic Clarity. And let’s hear it for Poly Acoustic Fence technology. It eliminates background noise to keep calls quiet wherever it’s noisy - from home offices to call centers.
Features:
Overview:
Manufacturer Warranty: 01 Year Limited Warranty
| User Interface Features | Gesture-based, multitouch-capable touchscreen 5-inch color LCD (720 x 1280 pixel) 9:16 aspect ratio Screensaver On-screen virtual keyboard Voicemail support Adjustable base height One USB type-A port (2.0 compliant) for media and storage applications One USB Type-C port (2.0 compliant) for media and storage applications Integrated Bluetooth 4.2 Unicode UTF-8 character support Adjustable font size selection (regular, medium, large) Normal and dark mode Multilingual user interface1 including Chinese, Danish, Dutch, English (Canada/US/UK), French, German, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Slovenian, Spanish, and Swedish |
| Audio Features | Poly HD Voice technology delivers lifelike voice quality for each audio path: handset, hands-free speakerphone, and optional headset Poly Acoustic Clarity technology provides full duplex conversations, acoustic echo cancellation, and background noise suppression Poly Acoustic Fence technology eliminates background noise when using a handset or wired headset Poly NoiseBlockAI technology removes most background noise when using the speakerphone even while you are talking TIA-920 wideband audio, type 1 compliant (IEEE 1329 full duplex) Frequency response—100 Hz–20 kHz for handset, optional headset, and handsfree speakerphone modes Codecs: G.711 (A-law and μ-law), G.729AB, G.722 (HD Voice), G.722.1 iLBC, OPUS Individual volume settings with visual feedback for each audio path Voice activity detection Comfort noise generation DTMF tone generation (RFC 2833 and in-band) Low delay audio packet transmission Adaptive jitter buffers Packet loss concealment OPUS support |
| Headset And Handset Compatibility | Dedicated RJ-9 headset port Hearing aid compatibility to ITU-T P.370 and TIA 504A standards Compliant with ADA Section 508 Subpart B 1194.23 (all) Hearing aid compatible (HAC) handset for magnetic coupling to hearing aids Compatible with commercially available TTY adapter equipment USB headset support Bluetooth headset support |
| Network And Provisioning | SIP protocol support SDP IETF SIP (RFC 3261 and companion RFCs) Two-port gigabit Ethernet switch Wi-Fi network connectivity 2.4-2.4835 GHz (802.11b, 802.11g, 802.11n HT-20), 5.15-5.825 GHz (802.11a, 802.11n, HT-20, 802.11n HT-40) 10/100/1000Base-TX across LAN and PC ports Conforms to IEEE802.3-2005 (Clause 40) for physical media attachment Conforms to IEEE802.3-2002 (Clause 28) for link partner auto-negotiation Manual or dynamic host configuration protocol (DHCP) network setup Time and date synchronization using SNTP FTP/TFTP/HTTP/HTTPS serverbased central provisioning for mass deployments Provisioning and call server redundancy supported1 QoS Support—IEEE 802.1p/Q tagging (VLAN), Layer 3 TOS, and DHCP VLAN-CDP, DHCP VLAN discovery, LLDP-MED for VLAN discovery - Network address translation support for static configuration and “keep-alive” SIP signaling RTCP and RTP support Event logging Syslog Hardware diagnostics Status and statistics reporting IPv4 and IPv6 TCP UDP DNS-SRV |
| Security | 802.1X authentication SRTP media encryption using AES-256 Transport layer security (TLS) Encrypted configuration files Digest authentication Password login Support for URL syntax with password for boot server address HTTPS secure provisioning Support for signed software executables Wi-Fi encryption: WEP, WPA-Personal, WPA2-Personal, WPA2-Enterprise with 802.1X (EAP-TLS, PEAP-MSCHAPv2) |
| Power | Built-in auto sensing IEEE 802.3af Power over Ethernet (Class 0) 13 W (Max) External universal AC/DC adapter (optional) 48 VDC @ 0.52 A (25 W) Energy Star rated |
| Regulatory Approvals | Argentina ENACOM Australia RCM Brazil ANATEL Canada ICES and NRTLC China SRRC China RoHS 2.0 EEA CE Mark Eurasian Customs Union EAC India WPC Indonesia SDPPI Israel MOC Japan MIC and VCCI Malaysia SIRIM Mexico IFETEL and NYCE NZ Telepermit Saudi Arabia CITC Singapore IMDA South Africa ICASA South Korea KC Taiwan NCC UAE TRA USA FCC and NRTL |
| Radio | USA–FCC Part 15.247 & FCC Part 15.407 Canada–RSS 247 Issue2 EU–ETSI EN 300 328 & ETSI EN 301 893 Japan–Article 2.1 Item 19-2 and 19-3 Australia–AS/NZ4268 |
| Safety | UL 62368-1 CAN/CSA C22.2 No. 62368-1-14 EN 62368-1 IEC 60950-1 and IEC 62368-1 AS/NZS 62368-1 |
| EMC | FCC Part 15 Class B ICES-003 Class B EN 55032 Class B EN 55024 EN 301 489-1 and EN 301 489-3 and EN 301 489-17 CISPR32 Class B VCCI Class B |
| Operating Conditions | Temperature: 0 to 40 °C (+32 to 104 °F) Relative humidity: 5% to 95%, noncondensing |
| Storage Temperature | -40 to +70 °C (-40 to +160 °F) |
| Poly Ccx 505 Business Media Phone Ships With | Console Handset with handset cord Network (LAN) cable-CAT-5E Desk stand Setup sheet |
| Size | 17.8 cm x 21.6 cm x 5.2 cm WxHxD (7.0 in x 8.5 in x 2.0 in WxHxD) |
| Weight | 1.28 kg (2.82 lbs) |
| Master Carton Quantity | Ten (10) |
