LCD panel type |
VA LCD |
Backlight type |
W-LED system |
Panel Size |
42.51 inch / 108 cm |
Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
Effective viewing area |
941.184 (H) x 529.416 (V) mm |
Aspect ratio |
16:9 |
Maximum resolution |
HDMI 1.4: 3840 x 2160 @ 30 Hz; HDMI 2.0 / DP / USB-C: 3840 x 2160 @ 60 Hz |
Pixel Density |
103.64 PPI |
Response time (typical) |
4 ms (Gray to Gray)* |
Brightness |
400 cd/m² |
Contrast ratio (typical) |
1000:1 |
SmartContrast |
50,000,000:1 |
Pixel pitch |
0.2451 x 0.2451 mm |
Viewing angle |
178º (H) / 178º (V)@ C/R > 10 |
Picture enhancement |
SmartImage |
Display colors |
Color support 1.07 billion colors |
Color gamut (typical) |
NTSC 105%*, sRGB 126%*, Adobe RGB 90%* |
HDR |
DisplayHDR 400 certified |
Scanning Frequency |
30 - 140 kHz (H) / 48 - 60 Hz (V) |
SmartUniformity |
93 ~ 105% |
Delta E |
< 2 (sRGB) |
sRGB |
Yes |
Flicker-free |
Yes |
LowBlue Mode |
Yes |
EasyRead |
Yes |
Adaptive sync |
Yes |
Signal Input |
DisplayPort 1.4 x 1, HDMI 2.0 x 2, HDMI 1.4 x 1, USB-C 3.2 Gen 2 x 1 (upstream, data, power delivery) |
HDCP |
HDCP 1.4 (HDMI 1.4 / HDMI 2.0 / DP 1.4 / USB-C), HDCP 2.2 (HDMI 2.0 / DP 1.4 / USB-C) |
HBR3 |
USB-C |
USB: |
Upstream: USB-C x 1, USB-B x 1; Downstream: USB 3.2 x 3 (with 1 fast charge B.C 1.2), USB-C x 1 (for PD 15W only) |
Audio (In/Out) |
Headphone out |
Sync Input |
Separate Sync |
RJ45 |
Ethernet LAN up to 1G*, Wake on LAN |
RS232 |
Yes |
USB-C |
Reversible plug connector |
Super speed |
Data and Video transfer |
DP |
Built-in Display Port Alt mode |
Power delivery |
USB PD version 3.0 |
USB-C max. power delivery |
USB-C1: up to 90 W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.5A), USB-C2: up to 15W (5V/3A) |
Built-in Speakers |
5 W x 2 |
Height adjustment |
100 mm |
Swivel |
-/+ 45 degree |
Tilt |
-5 ~ 23 degree |
ECO mode |
43.9 W (typ.) |
On mode |
46 W (typ.) (EnergyStar test method) |
Standby mode |
0.3 W (typ.) |
Off mode |
Zero watts with Zero switch |
Power LED indicator |
Operation - White
Standby mode- White (blinking) |
Power supply |
Built-in
100-240VAC, 50-60Hz |
Product with stand(max height) |
978 x 713 x 281 mm |
Product without stand (mm) |
978 x 573 x 78 mm |
Product with stand (kg) |
18.00 kg |
Product without stand (kg) |
12.40 kg |
Temperature range (operation) |
0°C to 40 °C |
Temperature range (storage) |
-20°C to 60 °C |
Relative humidity |
20%-80 % |
Altitude |
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
MTBF (demonstrated) |
70,000 hrs (excluded backlight) |
