General
Chipset A chipset is an electronic component in an integrated circuit known as a "Data Flow Management System" that manages the data flow between the processor, memory and peripherals.
Intel H610
Socket A CPU socket or CPU slot contains mechanical components providing mechanical and electrical connections between a processor and PCB. This allows for placing the CPU without soldering.
LGA 1700
Supports 12th Gen Intel Core Processors, Pentium Gold and Celeron Processors
BIOS Basic Input/Output System, also known as the System BIOS is firmware used to provide runtime services for operating systems and programs to perform hardware initialization during the booting process.
1x 256 Mb flash
UEFI AMI BIOS
ACPI 6.4, SMBIOS 3.4
Multi-language
Unique Features
Mystic Light
User Scenario
Hardware Monitor
Frozr AI Cooling
True Colo
Audio Boost
Mystic Light SYNC
Ambient Devices Support
Memory Boost
Core Boost
PCI-E Steel Armor
EZ M.2 Clip
CPU Cooler Tuning
Memory
RAM Capacity The total memory that can be added to a computer depends on the address registers built into the CPU.
upto 64GB (32GB each)
DIMM Slots DIMM (dual in-line memory module) slots are the place on your motherboard where the RAM goes.
2
RAM Frequency Supports RAM frequency is measured in MHz and usually immediately follows the DDR version in the RAM spec.
DDR5 1R 2133 / 2666 / 3200 MHz (by JEDEC & POR)
Slots And Ports
Expansion Slots An expansion slot is a socket on the motherboard that is used to insert an expansion card, which provides additional features to a computer such as video, sound, graphics, ethernet or memory.
1x PCIe x16 slot
1x M.2 slot (Key M, from H610 chipset)
Internal I/O Connectors An I/O (Input/Output) port is a socket on a computer that a cable is plugged into. The port connects the CPU to a peripheral device via a hardware interface or to the network via a network interface.
1x USB 3.2 Gen 1 5Gbps connector (From H610 chipset)
Supports additional 2 USB 3.2 Gen 1 5Gbps ports
1x USB 2.0 connector (From H610 chipset)
Supports additional 2 USB 2.0 ports
Back Panel Connectors The back or rear panel is the portion of the motherboard that allows you to connect external devices, such as your monitor, speakers, keyboard, mouse etc.
1x HDMI port
1x VGA port
1x DisplayPort port
1x PS/2 keyboard/ mouse combo port
4x USB 2.0 Type-A ports (From H610 chipset)
2x USB 3.2 Gen 1 5Gbps Type-A ports (From H610 chipset)
1x LAN (RJ45) jack
3x audio jacks
Software
Operating System Supports An operating system (OS) is system software that manages computer hardware, software resources, and provides common services for computer programs.
Support for Windows 11 64-bit, Windows 10 64-bit
Bundled Software
Drivers
MSI Center
Intel Extreme Tuning Utility
CPU-Z MSI GAMING
Google Chrome, Google Toolbar, Google Drive
Norton Internet Security Solution
1x HDMI 2.1
