Manufacture # Mercusys | Model # MR90X
Streaming or gaming on multiple devices brings more fun without dragging down performance. MR90X supports OFDMA and 4×4 MU-MIMO to power up your WiFi by allowing multiple clients to transmit at the same time. This delivers 4x greater network capacity and efficiency in traffic-dense environments. Interference from nearby wireless networks may cause issues with your signal, especially when you live in an apartment or close to your neighbors. MR90X supports BSS Coloring to mark the data frames from different APs. This helps minimize the signal interference from your neighbors to improve transmission efficiency.
Features:
Overview:
Manufacturer Warranty: 03 Years Limited Warranty
| Wireless | Wireless Standards: Compatible with 802.11ax/ac/a/b/g/n Wi-Fi standards Signal Rate: 4804 Mbps (5 GHz) + 1148 Mbps (2.4 GHz) Reception Sensitivity: 11g 6Mbps: -97dBm 11g 54Mbps: -79dBm 11n HT40 MCS7:-74dBm 11n HT20 MCS7:-77dBm 11a 6Mbps: -97dBm 11a 54Mbps: -79dBm 11ac VHT20 MCS8:-75dBm 11ac VHT40 MCS9:-71dBm 11ac VHT80 MCS9:-67dBm 11ax VHT20 MCS11:-67dBm 11ax VHT40 MCS11:-64dBm 11ax VHT80 MCS11:-61dBm Transmission Power: 2.4 GHz < 20dBm (EIRP) 5 GHz < 23dBm (band1, band2) 5 GHz < 30dBm (band3) Wireless Security: WPA / WPA2-Personal, WPA2 / WPA3-Personal Wireless Functions: Enable/Disable Wireless Radio, WMM |
| Software | WAN Type: Dynamic IP/Static IP/PPPoE/L2TP/PPTP Management: Access Control, Local Management, Remote Management DHCP: Server, DHCP Client List NAT Forwarding: Port Forwarding, Port Triggering, UPnP, DMZ Firewall Security: SPI Firewall, IP and MAC Address Binding Guest Network: 2.4 GHz Guest Network, 5 GHz Guest Network VPN Sever: OpenVPN, PPTP supported |
| Hardware | Dimensions (W X D X H): 8.2 × 6.8 × 1.6 in, (209 × 172.2 × 42.4 mm) Interfaces: 1x 2.5 Gbps WAN/LAN Port + 1x Gigabit WAN/LAN Port + 2x Gigabit LAN Ports Button: Reset/WPS Button Antenna Type: 8x Fixed Omni-Directional Antennas |
| Others | Package Contents: AX6000 8-Stream Wi-Fi 6 Router MR90X Power Adapter Quick Installation Guide RJ45 Ethernet Cable Environment: Operating Temperature: 0°C~40°C (32°F~104°F) Operating Humidity: 10%~90% Non-Condensing Storage Humidity: 5%~90% Non-Condensing |
