| Processor |
Intel Celeron J4105 (Quad Core 1.5GHz, up to 2.5GHz burst), Fanless |
| Graphics |
Integrated Graphics |
| Operation System |
Windows 10 IoT Enterprise LTSC |
| System Memory |
8GB (2x4GB) DDR4, 2666MHz, 2 SODIMM slots |
| Storage |
128GB SSD (M.2) |
| Display Support |
Up to 2 displays : 3840x2160@60Hz (via Display Port 1.2 out), 3840x2160@60Hz (via USB Type-C) |
| Expansion Slot |
M.2 Slots x 2 (Slot 1 : 128GB SSD, Slot 2 : Wi-Fi + Bluetooth card)
* Note: Slot 1 should be capable of supporting SATA, SO-DIMM x 2 (Slot 1 : 4GB DDR4, Slot 2 : 4GB DDR4) |
| TPM (Trust Platform Module) |
Hardware TPM 2.0 |
| VDI Support |
Citrix, VMware, Microsoft RDP, PCoIP S/W |
| Size (Inch) |
23.8 |
| Size (cm) |
60.47 cm |
| Aspect Ratio |
16:9 |
| Resolution |
1920 x 1080 |
| Panel Type |
IPS |
| Panel Multi |
BMS / LGD Module |
| Backlight Technology |
LED |
| Backlight Type |
Edge |
| Backlight Array |
H1B |
| Backlight Dimming Technology |
Global Dimming |
| Pixel Pitch |
0.2745 x 0.2745 mm |
| Brightness (Min.) |
200 cd/m² |
| Brightness (Typ.) |
250 cd/m² |
| Colour Gamut (Typ.) |
NTSC 72% (CIE1931) |
| Colour Depth (Number of Colours) |
16.7M |
| Colour Bit |
8bit (6bit+FRC) |
| Contrast Ratio (Min.) |
600:1 |
| Contrast Ratio (Typ.) |
1000:1 |
| Contrast Ratio with DFC |
Mega |
| Response Time |
5ms (GtG at Faster) |
| Viewing Angle (CR≥10) |
178º(R/L), 178º(U/D) |
| Surface Treatment |
Anti Glare, 3H |
| Webcam |
Yes (FHD, Integrated with Microphone, Pop-up type, no webcam app provided) |
| Black Stabilizer |
Yes |
| Colour Weakness |
Yes |
| Dynamic Action Sync |
Yes |
| Flicker safe |
Yes |
| Picture Mode |
Custom, Reader, Photo, Cinema, Colour Weakness, Game |
| Reader Mode |
Yes |
| Smart Energy Saving |
Yes |
| Super Resolution+ |
Yes |
| Management Console |
LG Cloud Device Manager |
| OnScreen Control (LG Screen Manager) |
Yes |
| HDMI |
Yes (1ea) |
| HDMI Version |
1.4 |
| HDMI (H-Frequency) |
30~85KHz |
| HDMI (V Frequency) |
56~75Hz |
| HDMI (HDCP Version) |
1.4 |
| HDMI (Max. Resolution at Hz) |
1920X1080 75Hz |
| Display Port |
Yes (out 1ea) |
| DP Version |
1.2 |
| DP (Max. Resolution at Hz) |
3840x2160 @ 60Hz |
| MIC & Headphone out combo |
Yes (1 x 3.5mm audio-mic combo jack (CTIA Type)) |
| USB |
2x USB 2.0 Type-A, 4 x USB 3.1 gen1 (5Gb/s) Type-A |
| USB-C |
Yes (out 1ea) |
| USB-C (DP Version) |
1.2 |
| USB-C (DP Alternate Mode) |
Yes |
| USB-C (Data Transmission) |
Yes |
| USB-C (Max. Resolution at Hz) |
3840×2160@60Hz |
| [Location] |
Vertical |
| Speaker |
Yes |
| Speaker Channel |
2ch |
| Speaker Output (unit) |
3W |
| Speaker Direction |
Down Firing |
| Maxx Audio |
Yes |
| AC Input |
100-240Vac, 50/60Hz |
| DC Output |
19V 5.79A |
| Power Consumption (DC Off) |
Less than 1.2W |
| Power Consumption (Energy Star) |
72.2Kwh |
| Power Consumption (Max.) |
68W |
| Power Consumption (Typ.) |
25W |
| Power Consumption (Sleep Mode) |
1.24W |
| Long Idle (Display Off) |
3.8W |
| Short Idle (Display On) |
17.5W |
| TEC (kWh) |
95.6KWh |
| Type |
External Power (Adapter) |
| Borderless Design |
Normal |
| Assembly Step |
Three-Step |
| Base Detachable |
Yes |
| Colour (Front Cabinet) |
Matt Black |
| Colour (Middle Cabinet) |
Matt Black |
| Colour (Back Cover) |
Matt Black |
| Colour (Stand Body) |
Matt Black |
| Colour (Stand Base) |
Matt Black |
| Display Position Adjustments |
Tilt/Height/Swivel/Pivot |
| Tilt |
-5º ~ 35º |
| Swivel |
0°~355° (±5°) |
| Pivot |
Bi-Direction |
| Height Range |
130mm |
| Down Height |
70mm |
| OneClick Stand |
Yes |
| Wall Mountable |
100 x 100 mm |
| Dimension in Shipping (W x H x D) |
614 x 462 x 174 mm |
| Dimension with Stand (W x H x D) |
553.4 x 382.7 x 240 mm |
| Dimension without Stand (W x H x D) |
553.4 x 332.7 x 59.4 mm |
| Pallet Stuffing (20ft/40ft/40ft HC) |
440/924/1008 |
| Weight in Shipping |
8.6 |
| Weight with Stand |
6.2 |
| Weight without Stand |
4.1 |
| CB |
Yes |
| CE |
Yes |
| EPA |
Yes (8.0) |
| EPEAT (Germany) |
BRONZE |
| EPEAT (USA) |
BRONZE |
| Energy Star |
Yes |
| ErP |
Yes |
| FCC-B |
Yes |
| HDMI |
Yes |
| KC (for Rep. of Korea) |
Yes |
| ROHS, REACH |
Yes |
| TUV-Ergo |
Yes |
| TUV-GS |
Yes |
| TUV-TYPE |
Yes |
| UL(cUL) |
Yes |
| VESA wall mount standard |
Yes |
| Adapter |
Yes |
| Adapter (Colour) |
Black |
| Power Cord |
Yes |
| Power Cord (Colour/Length) |
Black / 1.55m |
| External Antenna |
NO (Internal Antenna) |
| LAN |
1 x RJ45 : 10/100/1000 Base-T Gigabit Ethernet (Wake on LAN) |
| Wi-Fi |
Dual Band 802.11a/b/g/n/ac 2x2 (BT 5.0 Combo, Internal Antenna) |
| Bluetooth |
BT5.0 |
| HDMI (PC) |
1920x1080@75Hz |
| HDMI (Video) |
1920x1080@60Hz |
| Key Location |
Front |
| Key Number (Power Key Included) |
7 |
| Key Type |
Tact |
| LED Colour(On mode) |
White(AIO PC) |
| LED Colour(Power save mode) |
Blinking (AIO PC) |
| LED Colour(Standby) |
OFF(AIO PC) |
| Country |
English, German, French, Spanish, Italian, Swedish, Finnish, Portuguese, Polish, Russian, Greek, Chinese, Japanese, Korean, Ukrainian, Portuguese (Brazil), Hindi, Traditional Chinese |
| Number of Language |
18 |
| Box Printing Type |
Flexo |
| Handle |
Hand Hole |
| Packing Material |
EPS |
| Stacking Type |
Face Down |
| Stand Packing Type |
Detached |
| Humidity Range |
Operating : 20%~80%, Storage : 10%~90% |
| Temperature Range |
Operating : 10°C ~ 40°C, Storage : -20°C ~ 60°C |
