| PERFORMANCE |
| Display Size |
23.8"
|
| View Area |
527x296.5 mm
|
| Panel |
In-Plane Switching
|
| Backlight |
WLED
|
| Aspect Ratio |
16:9
|
| Resolution |
1920x1080
|
| Pixel Pitch |
0.2745x0.2745 mm
|
| Dot / Pixel Per Inch |
92 dpi
|
| View Angle (H / V) |
178° / 178°
|
| Response Time |
4ms GtG (Extreme mode) / 6ms GtG (Typical mode)
|
| Color Support |
16.7 Million
|
| Refresh Rate |
100Hz
|
| Brightness |
250 cd/m²
|
| Contrast Ratio |
1300:1
|
| Color Gamut |
99% sRGB
|
| Screen Surface Treatment |
Anti-glare
|
| Curvature |
Flat Panel
|
| Camera |
None
|
| Microphone |
None
|
| Speakers |
2Wx2
|
| Power Consumption (Typical / Maximum) |
13W / 24W
|
| Power Adapter |
Integrated
|
| DESIGN |
| Stand |
Tilt, Swivel, Pivot, Height Adjust Stand
|
| Case Color |
Raven Black
|
| Side Bezel Width |
2.0 mm
|
| Mounting |
Supports VESA mount 100 x 100 mm
|
| ThinkCentre M Series Support |
Tiny Support
|
| Dimensions (WxDxH)
|
- Lowest Position | 539.8 x 178.6 x 343.4 mm (21.25 x 7.03 x 13.52 inches)
- Highest Position | 539.8 x 178.6 x 498.4 mm (21.25 x 7.03 x 19.62 inches)
- Head Only | 539.8 x 44.0 x 325.7 mm (21.25 x 1.73 x 12.82 inches)
|
| Packaging Dimensions (WxDxH) |
710.0 x 111.0 x 421.0 mm (27.95 x 4.37 x 16.57 inches)
|
| Weight
|
- Monitor With Stand | 4.5 kg (9.9 lbs)
- Monitor Head Only | 2.9 kg (6.4 lbs)
|
| Packaging Weight |
6.4 kg (14.1 lbs)
|
| CONNECTIVITY |
| USB Port |
None
|
| Video Connector |
1x HDMI® 1.4, 1x DP 1.2, 1x VGA
|
| Network Connectivity |
None
|
| SERVICE |
| Base Warranty |
3-year
|
| CERTIFICATIONS |
| Environmental Certification |
ENERGY STAR® Certified, TCO 10, TCO Edge 2.1, EPEAT™ Gold, RoHS, EU Energy Efficiency Level (Level-C), Volatile Organic Compound Certification
|
| Ergonomic Certification |
TÜV Low Blue Light (Hardware solution), TÜV Rheinland® Flicker Free
|
| Sync Technology |
None
|
| Special Features |
Natural Low Blue Light
|
| SOFTWARE |
| Operating System |
Support Windows® 10, Windows 11
|
| ACCESSORIES |
| In the Box |
- Monitor with stand
- 1x HDMI® 1.4 cable (1.8m)
- 1x Power cable (1.8m)
- 4x Screws
- Quick setup guide
|
| MODEL INFORMATION |
| Model |
64BAMAR1AU
|
| Machine Type |
64BA
|
| Region |
APS
|
| EAN / UPC / JAN |
0198156755766 / 198156755766 / None
|
| Announce Date |
2025-06-09
|
