Kingston FURY Beast 32GB DDR5 6000MHz CL36 AMD Desktop Memory Black KF560C36BBE2K2-32

Description

Manufacture: Kingston | Model: KF560C36BBE2K2-32

Kingston FURY KF560C36BBE2K2-32 is a kit of two 2G x 64-bit (16GB) DDR5-6000 CL36 SDRAM (Synchronous DRAM) 1Rx8 memory modules, based on eight 2G x 8-bit FBGA components per module. Each module kit supports AMD® EXPO™ v1.1 and Intel® Extreme Memory Profiles (Intel® XMP) 3.0. The total kit capacity is 32GB. Each module has been tested to run at DDR5-6000 at a low latency timing of 36-44-44 at 1.35V. The SPDs are programmed to JEDEC standard latency DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact fingers. The JEDEC standard electrical and mechanical specifications are as follows:

Key Features:

• Power Supply: VDD = 1.1V Typical
• VDDQ = 1.1V Typical
• VPP = 1.8V Typical
• VDDSPD = 1.8V to 2.0V
• On-Die ECC
• Height: 1.37” (34.9mm), with heatsink

Factory Timing Parameters:

• Default (JEDEC): DDR5-4800 CL40-39-39 @ 1.1V
• EXPO Profile #0: DDR5-6000 CL36-44-44 @ 1.35V
• EXPO Profile #1: DDR5-5600 CL40-40-40 @ 1.25V
• XMP Profile #1: DDR5-6000 CL36-44-44 @ 1.35V
• XMP Profile #2: DDR5-5600 CL40-40-40 @ 1.25V
