Kingston 64GB DDR5-5600 CL46 SD Memory ECC Memory

Description

Manufacture: Kingston | Model: KSM56R46BD4PMI-64HA

Kingston's KSM56R46BD4PMI-64HAI is a 8G x 80-bit (64GB) DDR5-5600 CL46 SDRAM (Synchronous DRAM), 2Rx4, ECC, memory module, based on forty 4G x 4-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR5-5600 timing of 46-45-45 at 1.1V. Each 288-pin DIMM uses gold contact fingers. The electrical and mechanical specifications are as follows:

Features

• Power Supply: VDD = 1.1V Typical
• VDDQ = 1.1V Typical
• VPP = 1.8V Typical
• VDDSPD = 1.8V to 2.0V
• On-Die ECC
• x80 ECC (x40, 2 independent I/O sub channels)
• 32 internal banks
• Hard/Soft Post Package Repair
• Sideband access with I3C/I2C
• PCB: Height 1.23” (31.25mm)
• RoHS Compliant and Halogen-Free

Module Assembly

• DRAM : HYNIX (A-Die)
• RCD : IDT/Renasas
• PMIC : MPS
• SPD Hub : Montage
• TS : IDT/Renasas
