Sku: KF584CU40RWA-24
Brand: Kingston
Category: DDR4 Desktop Ram
Availability: On Order
On Order - These items are sourced upon request and may take longer to deliver. We will confirm availability once your order is received, as some products may occasionally be discontinued or unavailable.
Shipping Calculator
Find
DDR5 memory with 52 cycles CAS latency, 4800MT/s speed, and a 288-pin RDIMM form factor. It features a 32GB capacity, with low voltage of 1.2V, operating temperature range from 0°C to 85°C, and storage temperature from -55°C to 100°C.
We Accept
Manufacture: Kingston | Model: KF584CU40RWA-24
Kingston FURY KF584CU40RWA-24 is a 3G x 64-bit (24GB) DDR5-8400 CL40 Clocked Unbuffered DIMMs (CUDIMMs) 1Rx8, memory module, based on eight 3G x 8-bit FBGA components per module. The module supports Intel® Extreme Memory Profiles (Intel® XMP) 3.0. Each module has been tested to run at DDR5-8400 at a low latency timing of 40-52-52 at 1.45V. The SPDs are programmed to JEDEC standard latency DDR5-6400 timing of 52-52-52 at 1.1V. Each 288-pin DIMM uses gold contact fingers. The JEDEC standard electrical and mechanical specifications are as follows:
| CL | 52 cycles |
| Row Cycle Time (tRCmin) | 48ns (min.) |
| Refresh to Active/Refresh Command Time (tRFCmin) | 410ns (min.) |
| Row Active Time (tRASmin) | 32ns (min.) |
| UL Rating | 94 V - 0 |
| Operating Temperature | 0°C to +85°C |
| Storage Temperature | -55°C to +100°C |
