Sku: BX80708E2334
Brand: Intel
Category: Intel CPU
Availability: On Order
On Order - These items are sourced upon request and may take longer to deliver. We will confirm availability once your order is received, as some products may occasionally be discontinued or unavailable.
Shipping Calculator
Find
We Accept
Manufacture # Intel | Model # BX80708E2334
The Intel Xeon E-2334 Gen 4 is a Quad-Core (4-Core) 8-Threads Processor with a 3.4GHz base clock speed, 4.8GHz maximum turbo core speed and 8MB Intel Smart Cache. This processor specifically works with an LGA 1200 socket supported server motherboard.
Overview:
Manufacturer Warranty: 03 Years Limited Warranty
| Product Collection | Intel Xeon E Processor |
| Code Name | Products formerly Rocket Lake |
| Vertical Segment | Server |
| Processor Number | E-2334 |
| Lithography | 14 nm |
| Use Conditions | Server/Enterprise |
| CPU Specifications | |
| Total Cores | 4 |
| Total Threads | 8 |
| Max Turbo Frequency | 4.80 GHz |
| Intel Turbo Boost Technology 2.0 Frequency‡ | 4.80 GHz |
| Processor Base Frequency | 3.40 GHz |
| Cache | 8 MB Intel Smart Cache |
| Bus Speed | 8 GT/s |
| TDP | 65 W |
| Supplemental Information | |
| Marketing Status | Launched |
| Launch Date | Q3'21 |
| Servicing Status | Baseline Servicing |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types | DDR4-3200 |
| Max # of Memory Channels | 2 |
| Intel Optane™ Persistent Memory Supported | No |
| ECC Memory Supported ‡ | Yes |
| Expansion Options | |
| Scalability | 1S Only |
| PCI Express Revision | 4 |
| Microprocessor PCIe Revision | Gen 4 |
| PCI Express Configurations ‡ | Up to 1x16+1x4, 2x8+1x4, 1x8+3x4 |
| Max # of PCI Express Lanes | 20 |
| Advanced Technologies | |
| Intel Turbo Boost Technology ‡ | 2 |
| Intel Hyper-Threading Technology ‡ | Yes |
| Intel Transactional Synchronization Extensions | No |
| Intel 64 ‡ | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel SSE4.1, Intel SSE4.2, Intel AVX2, Intel AVX-512 |
| Idle States | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Security & Reliability | |
| Intel vPro Eligibility ‡ | Intel vPro Platform |
| Intel AES New Instructions | Yes |
| Secure Key | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes with Intel SPS |
| Default Maximum Enclave Page Cache (EPC) Size for Intel SGX | 0.5 GB |
| Intel Memory Protection Extensions (Intel MPX) | Yes |
| Intel OS Guard | Yes |
| Intel Trusted Execution Technology ‡ | Yes |
| Execute Disable Bit ‡ | Yes |
| Intel Boot Guard | Yes |
| Intel Virtualization Technology (VT-x) ‡ | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
| Intel VT-x with Extended Page Tables (EPT) ‡ | Yes |
