Sku: RNUC12WSKI50000
Brand: Intel
Category: Mini PC
Availability: On Order
On Order - These items are sourced upon request and may take longer to deliver. We will confirm availability once your order is received, as some products may occasionally be discontinued or unavailable.
Shipping Calculator
Find
Board Form Factor: UCFF (4" x 4"), Socket: Soldered-down BGA, Internal Drive Form Factor: M.2 SSD, Max Memory Size: 64 GB, USB Ports: 4, 03 Years Limited Warranty, RNUC12WSKI50000.
We Accept
Manufacture # Intel | Model # RNUC12WSKI50000
Intel NUC 12 Pro Kits raise the bar for performance and connectivity in a 4x4 device for productivity, collaboration, and edge compute. 12th Gen Intel Core processors plus up to 64GB dual channel memory and massive SSD capacity drive enterprise-class performance in a pint-sized PC. Collaboration is faster and easier than ever with lightning-fast wired and wireless connectivity options.
Overview:
Manufacturer Warranty: 03 Years Limited Warranty
| Product Collection | Intel NUC Kit with 12th Generation Intel Core Processors |
| Code Name | Products formerly Wall Street Canyon |
| Supported Operating Systems | Windows 11 Home Windows 11 Pro Windows 10 Home Windows 10 IoT Enterprise Windows 10 Pro Red Hat Linux Ubuntu 20.04 LTS. |
| Board Number | NUC12WSBi5 |
| Board Form Factor | UCFF (4" x 4") |
| Socket | Soldered-down BGA |
| Internal Drive Form Factor | M.2 SSD |
| Internal Drives Supported | 2 |
| TDP | 35 W |
| DC Input Voltage Supported | 12-20 VDC |
| Processor Included | Intel Core i5-1240P Processor (12M Cache | up to 4.40 GHz) |
| Total Cores | 12 |
| Total Threads | 16 |
| Lithography | Intel 7 |
| Max Turbo Frequency | 4.40 GHz |
| Max Memory Size (dependent on memory type) | 64 GB |
| Memory Types | DDR4-3200 1.2V SODIMMs |
| Max of Memory Channels | 2 |
| Max of DIMMs | 2 |
| ECC Memory Supported | No |
| Integrated Graphics | Yes |
| Graphics Output | Dual HDMI 2.0b w/HDMI CEC | Dual DP 1.4a via Type C |
| Displays Supported | 4 |
| PCI Express Revision | Gen 4 (m.2 22x80 slot) Gen 3 (otherwise) |
| PCI Express Configurations | PCIe x4 Gen 4 M.2 22x80 (key M) PCIe x1 Gen 3 M.2 22x42 (key B) PCIe x1 M.2 22x30 (key E) |
| M.2 Card Slot (wireless) | 22x30 (E) |
| M.2 Card Slot (storage) | 22x80 NVMe (M); 22x42 SATA (B) |
| USB Ports | 4 |
| USB Configuration | Front 2x USB 3.2 Rear 2x USB 4 (type C) 1x USB 3.2 1x USB 2.0 Internal 1x USB 3.2 on m.2 22x42 (pins) 2x USB 2.0 (headers) |
| Serial Port via Internal Header | No |
| Audio (back channel + front channel) | Front panel: 3.5mm headphone/mic jack |
| Integrated LAN | Intel Ethernet Controller i225-V |
| Integrated Wireless | Intel Wi-Fi 6E AX211(Gig+) |
| Integrated Bluetooth | Yes |
| Additional Headers | Front_panel (PWR RST 5V 5Vsby 3.3Vsby) Internal 2x2 power connector |
| Thunderbolt Ports | 2x Thunderbolt 4 |
| Intel Optane Memory Supported | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel ME Firmware Version | 16 |
| Intel HD Audio Technology | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Platform Trust Technology (Intel PTT) | Yes |
