Sku: GV-N506TWF2OC-16GD
Brand: Gigabyte
Category: nVidia
Availability: On Order
On Order - These items are sourced upon request and may take longer to deliver. We will confirm availability once your order is received, as some products may occasionally be discontinued or unavailable.
Shipping Calculator
Find
Product Type: Graphics Card, Model: GV-N506TWF2OC-16GD, GPU Chipset: GeForce RTX 5060 Ti (Blackwell), Core Clock: 2587 MHz, VRAM: 16GB GDDR7 (28 Gbps), CUDA Cores: 4608, Bus: PCI-E 5.0, Max Resolution: 7680 x 4320, Recommended PSU: 650W, Power Connectors: 1x 8-pin, Cooling: WINDFORCE System
We Accept
Manufacture # Gigabyte | Model # GV-N506TWF2OC-16GD
The WINDFORCE cooling system delivers exceptional thermal performance through a combination of cutting-edge technologies. It features server-grade thermal conductive gel, innovative Hawk fans with alternate spinning, composite copper heat pipes, a copper plate, 3D active fans, and screen cooling.
Key Features:
Manufacturer Warranty: 01 Years Limited Warranty
| Product Family | Gigabyte WINDFORCE OC Series |
| Model Number | GV-N506TWF2OC-16GD |
| Graphics Processing | GeForce RTX™ 5060 Ti |
| Architecture | NVIDIA Blackwell |
| Core Clock (OC Boost) | 2587 MHz (Reference card : 2572 MHz) |
| CUDA® Cores | 4608 |
| VRAM Size | 16GB |
| VRAM Type | GDDR7 |
| Memory Clock | 28 Gbps |
| Memory Bus | 128 bit |
| Card Bus | PCI-Express 5.0 |
| Digital Max Resolution | 7680 x 4320 |
| Multi-view Support | 4 Displays |
| I/O Ports | 3x DisplayPort 2.1b, 1x HDMI 2.1b |
| Power Connectors | 1 x 8-pin |
| Recommended PSU | 650W |
| Card Size (L x W x H) | L=208 W=120 H=40 mm |
| Cooling System | WINDFORCE (Dual Fan) |
| DirectX / OpenGL | DirectX 12 API / OpenGL 4.6 |
