Sku: 45-479-216
Brand:
Category: Monitor Brackets
Availability: On Order
On Order - These items are sourced upon request and may take longer to deliver. We will confirm availability once your order is received, as some products may occasionally be discontinued or unavailable.
Shipping Calculator
Find
ERGOTRON 45-479-216 HX Wall Dual Monitor Arm, For Up to 32" Screens, Capacity up to 35 lbs, Easily lifts, tilts, pans and rotates, VESA MIS-D, Streamline cable management, Portrait/landscape rotation with lockout, Quality design, WHITE
With the HX Wall Dual Monitor Arm, you can easily reposition two 32" monitors using patented Constant Force™ Technology.
We Accept
Manufacture # Ergotron | Model # 45-479-216
Ergotron 45-479-216 HX Dual Monitor Arm adds ergonomic adjustability to your heavy-duty monitors or TVs. Install a dual monitor set up on sturdy vertical surfaces or a wall with this HX arm and take advantage of this arm's curved hinged bow which grants viewing comfort. This HX arm's unique design enables individual monitor adjustment - pan from left to right about 8.5", 75 degrees tilt and 180 degrees rotation - letting you share work with colleagues or show information to a client. Besides the arm's retraction and ability to fold over the base when not in use makes it perfect for space constrained public areas like office, hospital and library lobbies.
Features:
Overview:
Manufacturer Warranty: 10 Year Limited Warranty
| Part Number | 45-479-216 |
| Description | HX Wall Dual Monitor Arm (white) |
| Arm | Folds back over the base into a compact retracted position; perfect for tucking under systems furniture storage shelves or cabinets in space constrained areas |
| Portrait/Landscape Rotation | Portrait/landscape rotation with lockout |
| Cable Management | Streamline cable management that routes cables under arm and within extension |
| Mounting Standards | VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm). The optional VESA Bracket Adaptor Kit (97-759) allows the attachment of displays with VESA hole patterns of 200 x 100, 200 x 200, 400 x 200 mm, 400 x 300 mm or 400 x 400 mm |
| Mounting Options | Attaches directly to sturdy vertical surfaces. Where applicable, apply to wood stud. Also attaches to wall track using bracket 97-091 (order separately) |
| Weight Capacity | Individual LCD weight = 5–17.5 lbs (2.3–7.9 kg) per monitor. Total LCD weight = 10–35 lbs (4.6–15.8 kg) |
| Hinge Bow | Hinge bow pivots 40° inward and 90° outward |
| Rotation | Monitor can be rotated 360° at connection point of arm and extension; rotation is restricted to 180° at connection point of extension and base |
| Tilt Range | 70° backward, 5° forward |
| Pivots | Feature quick install and release and feature effortless portrait to landscape 6° pan and tilt |
| Extended Reach | Up to 24.5" (60 cm) |
| Vertical Height Adjustment | 11.5" (29.2 cm) |
| Shipping Dimensions | 16" x 18.8" x 7.5" (48 x 41 x 19 cm) |
| Shipping Weight | 26.9 lbs (12.2 kg) |
| Warranty | Ten (10) years |
