| Image Sensor |
1/2.8" CMOS |
| Pixel |
4 MP |
| Max. Resolution |
2560 × 1440 |
| ROM |
128 MB |
| RAM |
512 MB |
| Electronic Shutter Speed |
1/1s–1/30000s |
| Scanning System |
Progressive |
| Min. Illumination |
Color: [email protected]; B/W: [email protected]; 0Lux (IR on) |
| Illumination Distance |
100 m (328.08 ft) (IR) |
| Illuminator On/Off Control |
Zoom Prio; Manual; Auto; Off |
| Illuminator Number |
6 (IR) |
| Lens Focal Length |
5 mm–125 mm |
| Max. Aperture |
F1.6–F3.6 |
| Field of View |
H: 51.9°–3.0°; V: 39.7°–2.2°; D: 63.1°–3.7° |
| Optical Zoom |
25× |
| Focus Control |
Auto; semi-auto; manual |
| Close Focus Distance |
0.5 m–5 m (1.64 ft–16.40 ft) |
| Iris Control |
Auto; manual |
| DORI Distance |
Detect: 2500 m (8202.10 ft); Observe: 987.5 m (3239.83 ft); Recognize: 500 m (1640.42 ft); Identify: 250 m (820.21 ft) |
| PTZ Pan/Tilt Range |
Pan: 0° to 360° endless; Tilt: –5° to +90°, auto flip 180° |
| Manual Control Speed |
Pan: 0.1°/s–240°/s; Tilt: 0.1°/s–160°/s |
| Preset Speed |
Pan: 240°/s; Tilt: 160°/s |
| Preset |
300 |
| Tour |
8 (up to 32 presets per tour) |
| Pattern |
5 |
| Scan |
5 |
| Power-off Memory |
Yes |
| Idle Motion |
Pattern; Preset; Scan; Tour |
| PTZ Protocol |
DH-SD |
| IVS (Perimeter Protection) |
Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking |
| Face Detection |
Supports face detection, face track box, capturing pictures, face enhancement; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing and quality first. |
| Auto Tracking |
Human and vehicle tracking based on Auto Tracking 1.0 technology |
| SMD 3.0 |
Smart Motion Detection 3.0 |
| Auto Patrol |
It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets |
| Video Compression |
H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+ |
| Streaming Capability |
3 streams |
| Resolution |
4M (2560 × 1440); 3M (2304 × 1296); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576); VGA (640 × 480); CIF (352 × 288) |
| Video Frame Rate |
Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps); Sub stream 1: D1/VGA/CIF@(1–25/30 fps); Sub stream 2: 720p/CIF @(1–25/30 fps) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 96Kbps - 14848Kbps; H.265: 38Kbps - 8960Kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| WDR |
120 dB |
| HLC |
Yes |
| White Balance |
Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp |
| Gain Control |
Auto; manual |
| Noise Reduction |
2D NR; 3D NR |
| Motion Detection |
Yes |
| Region of Interest (RoI) |
Yes |
| Image Stabilization |
Electronic (EIS) |
| Defog |
Electronic |
| Digital Zoom |
16× |
| Image Rotation |
180° |
| Privacy Masking |
Up to 24 areas can be set, with up to 8 areas in the same view |
| S/N Ratio |
≥ 55 dB |
| Audio Compression |
G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; PCM |
| Network Port |
RJ-45 (10/100 Base-T) |
| Network Protocol |
FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP; SAMBA |
| Interoperability |
CGI; SDK; ONVIF (Profile S&G&T); P2P |
| Streaming Method |
Unicast/Multicast |
| User/Host |
20 (total bandwidth: 64 M) |
| Storage |
Micro SD card (512 GB); FTP/SFTP; NAS |
| Browser |
IE 9 and later versions; Chrome 41 and later versions; Firefox 50 and later versions; iOS 10 and later versions |
| Management Software |
DMSS; DSS PRO |
| Mobile Client |
iOS; Android |
| Certifications |
CE: EN55032/EN55024/EN50130-4; FCC: Part15 subpartB, ANSI C63.4-2014; UL: UL62368-1 |
| Audio Input |
1 channel (LINE IN, bare wire) |
| Audio Output |
1 channel (LINE OUT, bare wire) |
| Alarm Linkage |
Capture; preset; tour; pattern; recordings on SD card; alarm digital input; send email |
| Alarm Event |
Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Alarm I/O |
2/1 |
| Audio I/O |
1/1 |
| Power Supply |
12 VDC/2 A ± 10% (included); PoE+ (802.3at) |
| Power Consumption |
Basic: 9.5 W; Max.: 21.5 W (illuminator on + fan on + PTZ) |
| Operating Temperature |
–40 °C to +65 °C (–40 °F to +149 °F) |
| Operating Humidity |
≤ 95% |
| Protection |
IP66, TVS 6000 V lightning proof; surge protection; voltage transient protection |
| Product Dimensions |
170.4 mm × Φ171.1 mm (6.71" × Φ6.74") |
| Net Weight |
2.5 kg (5.51 lb) |
| Gross Weight |
3.2 kg (7.05 lb) |
