| Camera :- |
|
| Image Sensor |
1/2.7" CMOS |
| Max. Resolution |
2960 (H) × 1668 (V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.003 [email protected] (Color, 30 IRE)
0.0003 [email protected] (B/W, 30 IRE)
0 lux (illuminator on) |
| S/N Ratio |
56 dB |
| Illumination Distance |
50 m (164.04 ft) (IR)
40 m (131.23 ft) (warm light) |
| Illuminator On/Off Control |
Auto/Manual |
| Illuminator Number |
2 (IR LED)
2 (warm light) |
| Angle Adjustment |
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
| Lens :- |
|
| Lens Type |
Motorized vari-focal |
| Mount Type |
φ16 |
| Focal Length |
2.7 mm–13.5 mm |
| Max. Aperture |
F1.0 |
| Field of View |
Horizontal: 113°–36°
Vertical: 57°–20°
Diagonal: 137°–40° |
| Iris Type |
Fixed |
| Close Focus Distance |
1.5 m (4.92 ft) |
| DORI Distance :- |
|
| Lens |
Detect| Observe| Recognize| Identify |
| W |
65.2 m| 26.1 m| 13.0 m| 6.5 m |
| T |
186.6 m| 74.6 m| 37.3 m| 18.7 m |
| Professional, intelligent :- |
|
| IVS (Perimeter Protection) |
Tripwire; intrusion (support the classification and accurate detection of vehicle and human) |
| SMD 4.0 |
Less false alarm, longer detection distance |
| Quick Pick |
With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events |
| Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| AI SSA |
Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions. |
| Video :- |
|
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265; AI H.264 |
| Video Frame Rate |
Main stream: 2960 × 1668@ (1–20 fps)/2688 × 1520 @ (1–30 fps)
Sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps)
Third stream: 1920 × 1080@ (1–30 fps) |
| Stream Capability |
3 streams |
| Resolution |
5M (2960 × 1668/2880 × 1620); 4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation |
Yes |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto; manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Image Stabilization |
Electronic Image Stabilization (EIS) |
| Smart Illumination |
Yes |
| Defog |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Audio :- |
|
| Built-in Mic |
Yes, built-in dual Mic |
| Built-in speaker |
Yes, built-in speaker |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm :- |
|
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; security exception |
| Network :- |
|
| Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Interoperability |
ONVIF (Profile S; Profile G; Profile T); CGI |
| User/Host |
20 (Total bandwidth: 72 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 256 G); NAS |
| Browser |
IE: IE8/9/11
Chrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Phone |
iOS; Android |
| Certification :- |
|
| Certification |
CE-LVD: EN 62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port :- |
|
| Audio Input |
1 channel (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
1 channel in: 5mA 3V–5 VDC |
| Alarm Output |
1 channel out: 300mA 12 VDC |
| Power :- |
|
| Power Supply |
12 VDC/PoE (802.3af) |
| Power Consumption |
Basic: 3.3 W (12 VDC); 4.4 W (PoE)
Max. (H.265+main stream/IR intensity+warm light on): 7.4 W (12 VDC); 8.7 W (PoE) |
| Environment :- |
|
| Operating Conditions |
–30 °C to +60 °C (–22 °F to +140 °F)/Less than 95% RH |
| Storage Conditions |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Protection Grade |
IP67 |
| Structure :- |
|
| Casing |
Metal + plastic |
| Dimensions |
288.4 mm × 94.4 mm × 84.7 mm
(11.35" × 3.72" × 3.33") (L × W × H) |
| Net Weight |
1.05 kg (2.31 lb) |
| Gross Weight |
1.35 kg (2.98 lb) |
