| Camera :- |
|
| Image Sensor |
1/2.7" CMOS |
| Max. Resolution |
2880 (H) × 1620 (V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.01 [email protected] (Color,30 IRE)
0.001 [email protected] (B/W,30 IRE)
0 lux (Illuminator on) |
| S/N Ratio |
>56 dB |
| Illumination Distance |
20 m (65.62 ft) (IR LED) |
| Illuminator On/Off Control |
Auto |
| Illuminator Number |
2 (IR LED) |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
| Lens :- |
|
| Lens Type |
Fixed-focal |
| Lens Mount |
M12 |
| Focal Length |
2.1 mm |
| Max. Aperture |
F2.0 |
| Field of View |
LDC is disabled:
Horizontal: 180°; Vertical: 78°; Diagonal: 180°
LDC is enabled (by default):
Horizontal: 170°; Vertical: 75°; Diagonal: 175° |
| Close Focus Distance |
0.6 m (1.97 ft) |
| DORI Distance |
Lens \ Detect \ Observe \ Recognize\ Identify
52.0 m \ 20.8 m \ 10.4 m \ 5.2 m |
| Intelligence :- |
|
| IVS (Perimeter Protection) |
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
| SMD 3.0 |
Less false alarm, longer detection distance |
| Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video :- |
|
| Video Compression |
H.265; H.264; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265; AI H.264 |
| Video Frame Rate |
Main stream: 2880 × 1620 @(1–20 fps )/2688 × 1520 @(1–25/30 fps )
sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps)
third stream:1920 × 1080 @ (1–25/30 fps) |
| Stream Capability |
3 streams |
| Resolution |
5M (2880 × 1620); 4M (2688 × 1520/2560 × 1440); 3M (2048 × 1536); 2304 × 296 ; 1080p(1920 × 1080)
1.3M (1280 × 960); 720p(1280×720); D1 (704× 576/704×480); VGA(640 × 480); CIF(352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120dB |
| Scene Self-adaptation (SSA) |
Yes |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto; Manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Defog |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 2688×1520 resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Audio :- |
|
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; PCM; G.726; G.723 |
| Alarm :- |
|
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; external alarm; SMD; security exception |
| Network :- |
|
| Network Port |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Cyber Security |
Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade |
| Network Protocol |
IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; P2P |
| User/Host |
20 (Total bandwidth: 64 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 256 GB); NAS |
| Browser |
IE
hrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Client |
iOS; Android |
| Certification :- |
|
| Certifications |
CE-LVD:EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port :- |
|
| Audio Input |
1 channel (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
1 channel in: 5 mA 3–5V DC |
| Alarm Output |
1 channel out: 1,000 mA 30V DC/500mA 50V DC |
| Power :- |
|
| Power Supply |
12 VDC/PoE |
| Power Consumption |
Basic: 3.1 W (12 V DC); 5.3 W (PoE)
Max. (H.265+main stream/IR intensity+IR on): 4 W (12V DC); 6.5 W (PoE) |
| Environment :- |
|
| Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH |
| Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Protection |
IP67 |
| Structure :- |
|
| Casing |
Metal |
| Product Dimensions |
249.3 mm × 90.7 mm × 90.4 mm (9.81" × 3.57" × 3.56") (L × W × H) |
| Net Weight |
820 g (1.81 lb) |
| Gross Weight |
1090 g (2.40 lb) |
