| Camera :- |
|
| Image Sensor |
1/2.8”4Megapixel progressive CMOS |
| Max. Resolution |
2560 (H) × 1440 (V) |
| ROM |
4GB |
| RAM |
1GB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
2.0 mm:
0.007 [email protected] (Color, 30 IRE)
0.0007 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on)
2.8 mm:
0.005 [email protected] (Color, 30 IRE)
0.0005 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on) |
| S/N Ratio |
>56 dB |
| Illumination Distance |
20 m (65.62 ft) (IR LED) |
| Illuminator On/Off Control |
Auto |
| Illuminator Number |
1 (IR LED) |
| Pan/Tilt/Rotation Range |
Tilt: –10° to 70° |
| Lens :- |
|
| Lens Type |
Fixed-focal |
| Lens Mount |
M12 |
| Focal Length |
2.0 mm; 2.8 mm |
| Max. Aperture |
2.0 mm: F2.0
2.8 mm: F1.6 |
| Field of View |
2.0 mm: Horizontal: 122°; Vertical: 72°; Diagonal: 141°
2.8 mm: Horizontal: 95°; Vertical: 52°; Diagonal: 114° |
| Iris Control |
Fixed |
| Close Focus Distance |
2.0 mm: 0.5 m (1.64 ft)
2.8 mm: 1.1 m (3.61 ft) |
| DORI Distance |
Lens | Detect | Observe | Recognize | Identify
2.0 mm | 44.8 m (146.98 ft) | 17.9 m (58.73 ft) | 9.0 m (29.52 ft) | 4.5 m (14.76 ft)
2.8 mm | 63.6 m (126.64 ft) | 25.4 m (50.52 ft) | 12.7 m (25.26 ft) | 6.4 m (12.80 ft) |
| Professional Intelligence :- |
|
| IVS (Perimeter Protection) |
Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection |
| Face Detection |
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting |
| People Counting |
Tripwire people counting, drawing polygonal lines for tripwire, generating and exporting report (day/week/month/year);
People counting in area, generating and exporting report (day/week/month);
Queue management, generating and exporting report (day/week/month);
4 rules can be set for tripwire, people counting in area and queue management;
Supports crowd detection;
Supports intelligence trajectory. |
| Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Abnormal Behavior Analysis |
Leave post detection which triggers alarms when no one is in the detection area, personnel have left their post or there is an abnormal number of people on duty in the detection area. Supports setting up to 20 personnel on duty at the same time. |
| Video :- |
|
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| Video Frame Rate |
Main stream: 2560 × 1440 @(1–25/30 fps )
Sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps)
Third stream: 1920 × 1080 @ (1–25/30 fps) |
| Stream Capability |
3 streams |
| Resolution |
4 M (2560 × 1440); 3 M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3 M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation (SSA) |
Yes |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Defog |
Yes |
| AFSA |
Yes |
| Image Rotation |
0°/90°/180°/270° (support 90°/270° with 2688×1520 resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Audio :- |
|
| Built-in MIC |
Yes |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; G.723 |
| Built-in Speaker |
Yes |
| Alarm :- |
|
| Alarm Event |
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; SMD; safety exception |
| Network :- |
|
| Network Port |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Network Protocol |
IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Cyber Security |
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI |
| User/Host |
20 (Total bandwidth: 64 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 256 G); NAS |
| Browser |
IE: IE 9 and later
Chrome
Firefox
Safari: Safari 12 and later |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Client |
iOS; Android |
| Certification :- |
|
| Certifications |
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC:47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port :- |
|
| RS-485 |
1 (baud rate range: 1200 bps–115200 bps) |
| Audio Input |
2 channels (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
2 channels in: 5 mA 3 V–5 VDC |
| Alarm Output |
2 channels out: 300 mA 12 VDC |
| Analog Output |
1 channel (CVBS output: BNC) |
| Power :- |
|
| Power Supply |
12 VDC/PoE (802.3af) |
| Power Consumption |
Basic: 4 W (12 VDC); 6.4 W (PoE)
Max. (H.265+main stream/IR intensity+IR on): 11.3 W (12 VDC); 12.9 W (PoE) |
| Environment :- |
|
| Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity |
≤95% |
| Protection |
IP67; IK10 |
| Structure :- |
|
| Casing |
Metal |
| Product Dimensions |
204.0 mm × 78.0 mm × 61.6 mm (8.03" × 3.07" × 2.43") (L × W × H) |
| Net Weight |
0.82 kg (1.81 lb) |
| Gross Weight |
1.18 kg (2.60 lb) |
