| Image Sensor |
1/1.8” CMOS |
| Max. Resolution |
3840 (H) x 2160 (V) |
| ROM |
128 MB |
| RAM |
1 GB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.003 [email protected] (Color, 30 IRE)
0.0003 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on) |
| S/N Ratio |
>56 dB |
| Illumination Distance |
40 m |
| Illuminator On/Off Control |
Auto; manual; zoom prior |
| Illuminator Number |
3 (IR LED) |
| Pan/Tilt/Rotation Range |
Pan: 0°–355°
Tilt: 0°–80°
Rotation: 0°–355° |
| Lens Type |
Motorized varifocal |
| Mount Type |
φ14 |
| Focal Length |
2.7 mm–12.0 mm |
| Max. Aperture |
F1.2 |
| Field of View |
Horizontal: 112.1°–47.5°
Vertical: 58.0°–26.6°
Diagonal: 137.5°–54.6° |
| Iris Control |
Auto |
| Iris Control Type |
P-Iris |
| Close Focus Distance |
W: 1.75 m
T: 5.21 m |
| DORI Distance |
Lens: W - T
Detect: 87.6 m - 186.6 m
Observe : 35.04 m - 78.64 m
Recognize : 17.52 m - 37.32 m
Identify : 8.76 m - 18.66 m |
| IVS |
Abandoned object; missing object |
| Heat Map |
Yes |
| IVS (Perimeter Protection) |
Tripwire; intrusion; fast-moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection |
| SMD 3.0 |
Less false alarm, longer detection distance |
| Face Detection |
Face detection; track; snapshot optimization; snapshot; face enhancement; face exposure; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimized snapshot, quality priority snapshot; face angle filter; optimization time setting |
| People Counting |
Support the counting of entering numbers, leaving a number and passing number, and displaying and outputting yearly/monthly/daily reports.
Support the counting of numbers in the area and 4 rules configuration. Count the number of people or stay time and link alarm.
Support queue management, and 4 rules configuration. Count the number of people or stay time and link alarm. |
| Intelligent Search |
Work together with Smart NVR to perform a refined intelligent search, event extraction and merging to event videos. |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265; AI H.264 |
| Video Frame Rate |
Mainstream: 3840x 2160 (1 fps–25/30 fps)
Substream: D1 (1 fps–25/30 fps)
Third stream: 1080p (1 fps–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability |
3 streams |
| Resolution |
3840 x 2160; 3072 x 2048; 3072 x 1728; 2592 x 1944; 2688 x 1520; 2048 x 1536; 2304 x 1296; 1080p (1920 x 1080); 1.3 MB (1280 x 960); 720p (1280 x 720); D1 (704 x 576/704 x 480); VGA (640 x 480); CIF (352 x 288/352 x 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264:3 kbps-20480 kbps
H.265:3 kbps-20480 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto; manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Image Stabilization |
Electronic Image Stabilization (EIS) |
| Defog |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 4 M resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
8 areas |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; scene changing; intrusion; tripwire; abandoned object; missing object; fast-moving; parking detection; loitering detection; people gathering; input abnormal detection; intensity change detection; people counting; face detection; people counting in area; stay alarm; people No. exception detection; queue management |
| Network Port |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Cyber Security |
Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade |
| Network Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P |
| User/Host |
20 (Total bandwidth: 80 M) |
| Storage |
FTP; SFTP; Micro SD card (Support max. 256 G); NAS |
| Browser |
IE: IE8 and later
Chrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Client |
iOS; Android |
| Certifications |
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07,UL 50E NEMA Type 4X (optional) |
| Port : - |
|
| RS-485 |
1 (baud rate range:1200 bps–115200 bps) |
| Audio Input |
1 channel (terminal) |
| Audio Output |
1 channel (terminal) |
| Alarm Input |
3 channels in: 5 mA 3–5 VDC |
| Alarm Output |
2 channels out: 1,000 mA 30 VDC/500 mA 50 VDC |
| Power Supply |
12 VDC (±25%)/24 VAC (±30%)/PoE (802.3at)/ePoE |
| Power Consumption |
Basic: 5.5 W (12 VDC); 6.0 W (24 VAC); 6.2 W (PoE)
Max. (H.265 + 3 streams + Intelligence + IR on + heating): 15.9 W (12 VDC); 18.1 W (24 VAC); 18.7 W (PoE)
Heating: 3.3 W ( 12 VDC); 4.4 W (24 VAC); 3.9 W (PoE) |
| Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH |
| Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Protection |
IP67, IK10 |
| Casing |
Metal |
| Product Dimensions |
Φ158 mm x 129.1 mm (Φ6.2″ x 5.1″) |
| Net Weight |
1.1 kg (2.4 lb) |
