Manufacture: Dahua | Model: DH-HAC-HFW3231EP-ZT-2712
Experience 1080P full HD video, a complete set of features, and the simplicity of reusing existing coaxial infrastructure with HDCVI. The Starlight HDCVI camera with 120dB true WDR presents a high-quality image with rich details even in extreme low-light conditions. It offers various auto-iris lens models with a multi-language OSD and multiple interfaces, including HD & SD video, audio, and alarm, all in an elegant case design. Its superior image performance and project-oriented features make the camera an ideal choice for mid to large-size businesses and projects in all industries.
Starlight Technology generates clear color images in near-complete darkness. A high-performing sensor and special algorithms work together to capture images in low-light and no-light environments.
| Image Sensor | 1/2.8" CMOS |
| Effective Pixels | 1945(H) × 1097(V), 2.1MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1.3s ~ 1/30000s NTSC: 1s ~ 1/30000s |
| Minimum Illumination | 0.005Lux/F1.4, 30IRE, 0Lux IR on |
| S/N Ratio | More than 65dB |
| IR Distance | Up to 100m (328 feet) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 4 |
| Lens Type | Motorized lens / Auto iris |
| Mount Type | Board-in |
| Focal Length | 2.7-12mm |
| Max Aperture | F1.4 |
| Angle of View | H: 95° ~ 36° |
| Focus Control | Auto / Manual |
| Close Focus Distance | 300mm (11.81") |
| Pan/Tilt/Rotation | Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360° |
| Resolution | 1080P (1920 × 1080) |
| Frame Rate | 25/30fps @ 1080P, 25/30/50/60fps @ 720P |
| Video Output | 1-channel BNC HDCVI high definition video output & 1-channel BNC CVBS video output & 1-channel BNC SDI video output, CVBS tester out |
| Day/Night | Auto (ICR) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / WDR |
| WDR | 120dB |
| Gain Control | AGC |
| Noise Reduction | 2D / 3D |
| White Balance | Auto / Manual |
| Smart IR | Auto / Manual |
| Audio Input | 1-channel audio in |
| Alarm Input/Output | 1-channel alarm in & 1-channel alarm out |
| Power Supply | AC 24V±25% / DC 12V±25% |
| Power Consumption | Max 16.6W (12V DC, IR on) |
| Operating Conditions | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH * Start-up should be done at above -30°C (-22°F) |
| Storage Conditions | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| Ingress Protection & Vandal Resistance | IP67 & IK10 |
| Casing | Aluminium |
| Dimensions | 273.2mm × 95.0mm × 95.0mm (10.76" × 3.74" × 3.74") |
| Net Weight | 1.16kg (2.56lb) |
| Gross Weight | 1.52kg (3.35lb) |
