Cooler Master MWE 1250W 80+ Gold Fully Modular ATX 3.1 Power Supply Black

Sku: MPE-C501-AFCAG-3EAU

Brand: Cooler Master

Category: Power Supplies

$295.90

Shipping Information

Availability: In Stock

Ships in 1-2 days.

Pickup from Seven Hills in 1-2 days.

Shipping Calculator

1250W ATX power supply with 80 PLUS Gold efficiency, Active PFC, and fully modular design. Features a 140mm Two Ball Bearing fan, high-efficiency performance, and comprehensive protections (OVP, OPP, SCP, OCP, UVP) for reliable and stable power delivery.

-
+

We Accept

Thumbnail 3

Description

Manufacture: Cooler Master | Model: MPE-C501-AFCAG-3EAU



The Cooler Master MWE Gold 1250W power supply is engineered for high-performance computing, offering exceptional efficiency and power stability. With an 80 PLUS Gold certification, it achieves ≥90% efficiency at typical loads, reducing energy consumption and heat output. Its fully modular design allows for cleaner cable management and improved airflow, making it ideal for gaming and workstation builds. The PSU features a durable 140mm two-ball bearing fan for superior cooling and longevity. Built to ATX 3.1 standards, it includes a 12V-2x6 connector for the latest high-power GPUs. Comprehensive protections, including OVP, OPP, SCP, and OTP, ensure safe and reliable operation, making it a robust choice for power-hungry systems.



Key Features:



  • 1250W Power Output for High-End Systems
  • 80 PLUS Gold Certified for ≥90% Efficiency
  • Fully Modular Design for Easy Cable Management
  • ATX 3.1 Standard for Next-Gen Compatibility
  • 140mm Two-Ball Bearing Fan for Efficient Cooling
  • Active PFC for Stable Power Delivery
  • Comprehensive Safety Protections: OVP, OPP, SCP, OCP, UVP, OTP
  • 12V-2x6 Connector for High-Power GPUs
  • 12 SATA Connectors for Extensive Storage Support
  • Reliable Build Quality with >100,000 Hours MTBF

ATX Version ATX Rev. 3.1
PFC Active PFC
Input Voltage 100-240V
Input Current 15-7A
Input Frequency 50-60Hz
Dimensions (L x W x H) 180 x 150 x 86 mm
Fan Size 140mm
Fan Bearing Two Ball Bearing
Efficiency ≥90% @ Typical Load
80 PLUS Rating 80 PLUS Gold
ErP 2014 Lot 3 Yes
Operating Temperature 0-50°C
Power Good Signal 100 - 150 ms
Hold Up Time ≥16ms at 100% Load
MTBF >100,000 Hours
Protections OVP / OPP / SCP / OCP / UVP / OTP / Inrush Protection
Regulatory TUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS
ATX 24 Pin Connectors 1
EPS 4+4 Pin Connectors 1
EPS 8 Pin Connector 1
SATA Connectors 12
Peripheral 4 Pin Connectors 4
PCI-e 6+2 Pin Connectors 3
12V-2x6 Connectors 1
Series MWE Gold Series
Category Above 750W
Modular Fully Modular
80 Plus Efficiency Gold
Form Factor ATX
Watts 1250W
